Specifications
Brand Name :
E-link
Model Number :
LNK-DEC140P-R
Certification :
CE FCC RoHS
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiated
Payment Terms :
T/T, Western Union, MoneyGram, PayPal
Supply Ability :
1000pair per mouth
Delivery Time :
3-10 working days
Packaging Details :
Ethernet over Coax Receiver standard exxport package
Input Power :
48-57VDC (2 pin connector)
Power Consumption :
10W Max. w/o PoC /250W Max. w/PoC
Coaxial Distance :
300m
Dimensions (W x D x H) :
95 × 67 × 30 mm
Weight :
0.5 Kg
Casing :
Aluminum case
Description

DIN-Rail Receiver of 4-port Coax to 1-port 10/100Base-TX Ethernet Switch with PoC

Ethernet over Coax Receiver​ Overview

This DIN-rail EOC receiver, used in conjunction with the LNK-DEC110P-T transmitter, aggregates

four 10/100Base-TX Ethernet signals over coaxial cable to a single 10/100Mbps Ethernet port,

with a maximum transmission distance of 800 meters. Supporting PoC technology, it eliminates

the need for additional power at the transmitter or PoE-enabled IP camera. It's ideal for

upgrading analog surveillance systems to network-based systems using existing coaxial cables and

is widely used in CCTV system upgrades and remote network expansion.

Ethernet over Coax Receiver​ Features

  • Ethernet Extension: Security Link over Coax
  • Support DIN-Rail mount installation
  • Connecting up to 4 x LNK-DEC110P and IP Cameras
  • 1000Mbps Full-duplex communication
  • Power over Coaxial
  • Data Rate up to (per port): 40Mbps (Downlink)/ 10Mbps (Uplink)
  • Max. Distance: 800m over Coax (RG59/U)
  • Auto MDI/MDI-X for reliable detection and correction for straight-through and crossover cables
  • External 48~57VDC power input
  • Wall mount installation

Ethernet over Coax Receiver Technical Indexes

Ethernet
Standards IEEE802.3 10Base-T
IEEE802.3u 100Base-TX
Cabling 100Base-TX: Cat5 or above
Maximum Distance Cat5UTP up to 100m
Connector 1 x RJ45
Coaxial
Cabling Coaxial Cable (75 ohm)
Connector 4 BNC (female)
Distance 300m
Data Rate per port 40Mbps Max. (Downlink)
10Mbps Max. (Uplink)
Technology Power Line Communication (PLC)
Protection
Reverse Polarity Present
Overload Protection Present
Electrical and Mechanical
Input Power 48-57VDC (2 pin connector)
Power Consumption 10W Max. w/o PoC
250W Max. w/PoC
Dimensions (W x D x H) 95 × 67 × 30 mm
Weight 0.5 Kg
Casing Aluminum case
Environmental
Operation Temperature -10˚C to 60˚C (14˚F to 140˚F)
Storage Temperature -40˚C to 85˚C (-40˚F to 185˚F)
Relative Humidity 5% to 90% non-condensing
MTBF > 100,000 hrs
Regulatory Approvals

ISO9001

FCC Part 15 Class A

EN55022 Class A

Surge Protection

RJ45: 1KV

BNC: 2KV

Power: 500V

Ethernet over Coax Receiver Dimension & Size

DIN-Rail Ethernet over Coax Receiver with 4-Channel Input and PoC Function

Ethernet over Coax Receiver Ordering Information

Model Description
LNK-DEC140P-R DIN-Rail Receiver of 4-port Coax to 1-port 10/100/1000Base-TX Ethernet Switch with PoC

Ethernet over Coax Receiver Application

DIN-Rail Ethernet over Coax Receiver with 4-Channel Input and PoC Function
