GYTC8S Figure 8 Fiber Optic Cable Stranded Wires Messenger Aerial Overhead
GYTC8S Figure 8 Fiber Optic Cable Stranded Wires Messenger Aerial Overhead
GYTC8S Figure 8 Fiber Optic Cable Stranded Wires Messenger Aerial Overhead
GYTC8S Figure 8 Fiber Optic Cable Stranded Wires Messenger Aerial Overhead
GYTC8S Figure 8 Fiber Optic Cable Stranded Wires Messenger Aerial Overhead
GYTC8S Figure 8 Fiber Optic Cable Stranded Wires Messenger Aerial Overhead
Specifications
Brand Name :
JQ/OEM
Model Number :
GYTC8S
Certification :
CE/ISO9001
Place of Origin :
Guangdong, China
MOQ :
1 Kilometer
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
8000 kilometers per month
Delivery Time :
2-5days
Packaging Details :
Wooden Drum
Type :
Outdoor Fiber Optic Cable
Number of Conductors :
≥ 10
Fiber type :
G652D Single mode or as your request
Color :
Customized
Jacket :
PE,MDPE,LSZH,PVC
Central strength member :
Steel wire
Armored :
Steel tape
Package :
Wooden Drum/Customized
Application :
Aerial,Overhead
Oem :
Available
Warranty :
25 years
Production Name :
figure 8 fiber optic cable
Life Time :
25 years
Installation :
Aerial
Armor Material :
Corrugated Steel Tape
Crush Resistance :
1000N/100mm
Out Sheath :
LSZH, PE
Outer Diameter :
7.0mm-9.0mm
Fiber Per Tube :
12 core
Self Support :
with Steel Messenger self Support
Outer Sheath Material :
LSZH PE HDPE
Structure :
Loose tube
Useful :
Figure 8
Standards :
RoHS, UL, ETL, IEC
Strengthen Member :
Steel wire strengthen
Description

The figure-8 aerial fiber optic cable employs a self-supporting design where optical fibers are encased in gel-filled loose buffer tubes, which are stranded concentrically around a non-metallic central strength member. To ensure waterproof integrity, the cable core is treated with water-blocking gel or equivalent sealing compounds that inhibit moisture penetration and longitudinal migration. For mechanical reinforcement, the structure incorporates corrugated steel tape armor. The complete assembly, including the load-bearing galvanized steel messenger wire, is enclosed within a protective black polyethylene (PE) outer sheath for environmental durability.
GYTC8S Figure 8 Fiber Optic Cable Stranded Wires Messenger Aerial Overhead

Characteristics:
1. Central loose tubes with jelly compound inside to protect the cladding fiber.
2. Corrugated steel tape laminated with plastic at both sides bonding to PE sheath.
3. The cross-section in fig8 shape.
4. Incorporates stranded steel messenger wire.
Applications:
Long and local area network(LAN) communication.
Aerial & conduit/duct application.

Specification:

item value
Model Number GYTC8S
Type Outdoor Fiber Optic Cable
Place of Origin Guangdong,China
Brand Name jiqian
Structure multi loose tube
Number of Conductors ≥ 10
Fiber count 2-144 Cores
Fiber Type G652D Single mode or as your request
Central strength member steel wire
Loose tube Jelly filled
Loose tube PBT
Jacket Sheath PE
Color Black or as your need
Package Plywood Reel/customized
Application Aerial,Overhead
operating temperature -40 to +70
Certification CE/ROHS/ISO9001 /ANATEL

Optical Characteristics:

G.655 50/125μm 62.5/125μm
G.652
Attenuation '@850nm ≤3.0 dB/km
(+20℃) '@1300nm ≤1.0 dB/km
'@1310nm ≤0.34 dB/km ≤0.40 dB/km
'@1550nm ≤0.21 dB/km ≤0.23 dB/km
'@850nm ≥500 MHz·km
'@1300nm ≥1000 MHz·km
Numerical Aperture 0.200±0.015NA

Company Profile:

Guangzhou Jiqian Fiber Optic Cable Co.Ltd. is located in 2nd Floor,Building B3,Building 3 No.43 Lixin 9th Road,Xintang Town,Zengcheng District,Guangzhou city,Guangdong province,China.It is a large-scale high-tech specialized joint-stock enterprise that integrates scientific research, development,production, and sales. It specializes in producing various types and specifications of optical cables with 2-288 cores. The company adheres to the corporate spirit of "integrity, speed, flexibility, efficiency, and innovation", and strives for perfection, appreciation for customers, and paving the way for success, Adhere to the standard that "customer satisfaction is the most important measure of our performance".

We are committed to collaborating with global partners by offering premium products, competitive pricing, and exceptional service to achieve mutual success. Our doors are always open for international clients to tour our production facilities and establish enduring partnerships.

GYTC8S Figure 8 Fiber Optic Cable Stranded Wires Messenger Aerial OverheadGYTC8S Figure 8 Fiber Optic Cable Stranded Wires Messenger Aerial Overhead

WHY CHOOSE US:

GYTC8S Figure 8 Fiber Optic Cable Stranded Wires Messenger Aerial Overhead

Certification:

GYTC8S Figure 8 Fiber Optic Cable Stranded Wires Messenger Aerial Overhead

FAQ:

1. who are we?
We are based in Guangdong, China, start from 2017,sell to Africa(33.00%),South America(17.00%),Western Europe(17.00%),Mid East(17.00%),Southeast Asia(9.00%),South Asia(7.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Fiber Optic Cable, FTTH Drop Cable, Communication Cables, Outdoor/Indoor Fiber Cable
4. what services can we provide?
Accepted Delivery Terms: FOB,EXW；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese

5.MOQ: what is your minimum quantity?
-MOQ : 1KM
6.Can I get a sample?
-Yes, we provide FREE sample and you just need to pay for express freight.
7.Accept OEM or ODM?
-Yes,we're manufacturer. And we have our own Engineering Department. You just need to tell us your requirements.
8.What is your delivery time?
-The general delivery time is 3-7 days after order confirmed. It depends on the order quantity.
