Specifications
Brand Name :
jiqian
Model Number :
GYTC8S
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1000m
Payment Terms :
Western Union, MoneyGram, T/T, L/C
Supply Ability :
100km per 2 day
Delivery Time :
2-4day
Packaging Details :
wooden drum
Fiber type :
single mode & multi mode
Oem :
Available
Application :
Aerial
Number of conductors :
12 24 48
Structure :
Stranded Loose tube
Operating temperature :
-40 ~ +60 C
Length :
1KM OR 2KM OR 500M
Description

GYTC8S Figure 12 24 Stranded Loose Tube Messenger Wire Aerial outdoor Fiber Optic cable

Figure-8 optical fiber cable with metallic central strength member of steel wire/strand and moisture barrier inner sheath incorporating steel messenger wire suitable for overhead installation as pole-to-pole or pole-topremises.Tubes contain optical single-mode or multimode fibers color coded as per the color coding scheme.

12 24 48 Core Outdoor Overhead Self Supporting Figure 8 Fiber Optic Cable Gytc8a Gytc8s
12 24 48 Core Outdoor Overhead Self Supporting Figure 8 Fiber Optic Cable Gytc8a Gytc8s
12 24 48 Core Outdoor Overhead Self Supporting Figure 8 Fiber Optic Cable Gytc8a Gytc8s12 24 48 Core Outdoor Overhead Self Supporting Figure 8 Fiber Optic Cable Gytc8a Gytc8s
2.Technical specification
Cable Specification:
Item Name:GYTC8S cable
Optical Mode:Singlemode/Multimode
Fiber Diameters:G652, G655, 50/125μm, 62.5/125μm
Total Fiber Count:2-144
Bend Radius(Static/Dynamic):10D/20D
Working Life:More than 25 years
Application:Aerial self-supporting,Local network,Local network,Long distance network communication.

Structure:
Figure 8 non armoured fiber cable consists of :
1.Stranded loose tube
2.Steel wire strength member
3.Core filler compound
4.Fillers
5.Phosphating or Galvanized steel wire
6.PE sheath
Standards and Certificate:
Fiber optical cable complies with Standard YD/T 769-2003,IEC60794-1
Certificate:CE ROHS ISO9001
Characteristics:
· Good mechanical and temperature performance
· High strength loose tube that is hydrolysis resistant
· Special tube filling compound ensure a critical protection of fiber
· Crush resistance and flexibility
3.Optical Characteristics:
G.652D
50/125μm
62.5/125μm
Attenuation (+20℃)
@850nm
≤3.0 dB/km
≤3.0 dB/km
@1300nm
≤1.0 dB/km
≤1.0 dB/km
@1310nm
≤0.36 dB/km
@1550nm
≤0.22 dB/km
Bandwidth (Class A)
@850nm
≥500 MHz·km
≥200 MHz·km
@1300nm
≥1000 MHz·km
≥600 MHz·km
Numerical Aperture
0.200±0.015NA
0.275±0.015NA
Cable Cut-off Wavelength λcc
≤1260nm
4.Technical Parameters:
Performance
Long-term
Short-term
Max.Tension(N)
3500
7000
Max.Crushing
300
1000
Resistance(N/100mm2)
30D(Dynamic)
15D(static)
Storage and operating temperature
-40℃ to +70℃
