2.54 Double Row Vertical Right Angle 2x4-pin PCB Male-Female Connector Headers
2.54 Double Row Vertical Right Angle 2x4-pin PCB Male-Female Connector Headers
2.54 Double Row Vertical Right Angle 2x4-pin PCB Male-Female Connector Headers
2.54 Double Row Vertical Right Angle 2x4-pin PCB Male-Female Connector Headers
2.54 Double Row Vertical Right Angle 2x4-pin PCB Male-Female Connector Headers
2.54 Double Row Vertical Right Angle 2x4-pin PCB Male-Female Connector Headers
2.54 Double Row Vertical Right Angle 2x4-pin PCB Male-Female Connector Headers
2.54 Double Row Vertical Right Angle 2x4-pin PCB Male-Female Connector Headers
Specifications
Package :
Tape Wrapping
Temperature Range :
-40 To 85 Degrees Celsius
Termination Style :
Solder
Brand Name :
XTKCONN
Model Number :
Wafer Housing Terminal
Certification :
CE,SGS,ROHS,ISO9001
MOQ :
1000pcs
Price :
Negotiable Price
Packaging Details :
Inner Package:in Reel; Outer Package: Reel In Carton
Delivery Time :
5-7 Days
Payment Terms :
L/C,T/T,Payyal
Supply Ability :
3KK Pcs
Material :
Plastic
Durability :
High
Contact Pin Material :
Phosphor Bronze
Current Rating :
5A
Connection Type :
Snap-On
Description

2.54mm 90‑degree Dual Row 2×4P Pin Header & Female Socket, Right Angle 8‑Pin PCB Header Male‑Female Pair



Product Description

Item Specification
Full Product Name 2.54 Double Row Vertical Right Angle 2x4‑pin PCB Male‑Female Connector Headers
Pitch 2.54 mm (0.100 inch)
Pin Configuration Double Row, 2×4‑pin (Total 8 Contacts)
Mounting Style Right‑Angle 90° Through‑Hole (DIP)
Mating Type Male Header + Female Receptacle Matching Set
Pin Dimension 0.64 mm Square Standard Pin
Rated Current 3 A Max per contact
Rated Voltage 250 V AC/DC RMS
Dielectric Withstanding Voltage 600 V AC, 1 min
Contact Resistance ≤ 20 mΩ
Insulation Resistance ≥ 1000 MΩ
Operating Temperature Range -40 ℃ ~ +105 ℃
Soldering Condition 260 ℃, 10 s max
Flammability Grade UL94V‑0
Compliance RoHS 2.0, REACH compliant
Optional Customization Plating thickness, locating post, polarizing key, pin length, housing height, cut‑to‑length

Our 2.54mm pitch double‑row right‑angle (90°) 2×4‑pin male‑female PCB header set is a widely‑adopted through‑hole board‑to‑board interconnect solution. Designed for side‑mount PCB stacking, it realizes horizontal‑direction board interconnection in limited enclosure space. This matched male‑female combo eliminates mismating risk for prototype, industrial control, IoT, and embedded hardware. Standard 0.100‑inch pitch keeps full compatibility with mainstream PCB footprints, breadboards and legacy equipment, available for bulk stock and OEM custom modification.

2.54 Double Row Vertical Right Angle 2x4-pin PCB Male-Female Connector Headers2.54 Double Row Vertical Right Angle 2x4-pin PCB Male-Female Connector Headers

Material Composition


Insulator Housing

  • Base Material: High‑temperature PBT / PA6T + 30% Glass Fiber Reinforced (Black)
  • Flame retardant UL94V‑0, anti‑deformation during wave soldering, excellent dimensional stability under wide temperature swing, resistant to common flux chemical erosion.

Contact Terminals

  • Base Material: High‑grade Brass / Phosphor‑Bronze, good spring performance, anti‑fatigue for repeated plug‑in cycles.
  • Under‑plating: Nickel barrier layer to prevent base‑metal diffusion.
  • Surface Plating Options:
    1. Gold flash plating (0.03‑0.1 μm): Anti‑oxidation, stable signal for long‑term storage & low‑signal circuits
    2. Pure tin plating: Cost‑optimized for general‑purpose power‑signal applications
Plating thickness can be adjusted per customer drawing requirements.

2.54 Double Row Vertical Right Angle 2x4-pin PCB Male-Female Connector Headers

2.54 Double Row Vertical Right Angle 2x4-pin PCB Male-Female Connector Headers


Ordering & Custom Remarks

  1. Standard part: 2.54mm Double Row Right‑Angle 2×4‑pin Male‑Female set (through‑hole, tin or gold plating)
  2. Deliverables available: 2D dimension drawing, PDF datasheet, material RoHS certificate, sample support.
  3. Related expandable series: We produce a full 2.54mm header & female header range: single/dual row, vertical/right-angle, THT / SMD type, pin count from 2×2 up to 2×40 positions.
