Female Three Row 2-50 Pin Header Connector 2.0mm Pitch Board To Board PCB Connector
Female Three Row 2-50 Pin Header Connector 2.0mm Pitch Board To Board PCB Connector
Female Three Row 2-50 Pin Header Connector 2.0mm Pitch Board To Board PCB Connector
Female Three Row 2-50 Pin Header Connector 2.0mm Pitch Board To Board PCB Connector
Specifications
Withstand Voltage :
500V AC/DC
Operation Temperature :
-40℃ To +105℃
Insulation Resistance :
1000MΩ Min
Brand Name :
XTKCONN
Model Number :
Female Header connector
Certification :
CE,SGS,ROHS,ISO9001
Place of Origin :
Guangdong,China
MOQ :
500pcs
Price :
Negotiable price
Payment Terms :
L/C,T/T,Payyal
Supply Ability :
4KK pcs
Delivery Time :
5-7 days
Packaging Details :
vacuum package,boxes in carton
Contact Material :
Contact Material
Current Rating :
3AMP
Number Of Row :
3Rows
Description

Female Three-Row 2-50 Pin Header Connector 2.0mm Pitch Board To Board PCB Connector


Specifications


1. Pitch: 2.00 mm

2. Connector Name: PCB Connector/Female Header

3. Insulation Material:PA9T UL 94-V0

4. Contact Material: Copper Alloy

5: Mounting Type: Through Hole

6: Number of Row: Single

7: Contact Finish: Gold Over Nickel

8: Termination: Solder

9: Color:Black

10: Current Rating:2.0A

11: Withstand Voltage:500V AC/DC

12: Contact Resistance:20mΩ Max

13: Pin Length: Customization

14: Pin Available:2Pins to 40Pins

15. Number of Rows: Three Rows

16. Fastening Type: Push-Pull

17. Style: Board to Board

18. Contact Type: Female Socket

19. Plastic Height: 6.35 mm +/- 0.15


Custom Headers provide design flexibility and production efficiency while reducing the need for equipment assets. With horizontal, right-angle, and vertical orientations, and single and dual Rows.


Environmental

1. Storage Temperature -40°C~105°C Relative Humidity <80%.
2. Operation Temperature -40°C~+105°C
Lead-free process, compliant with RoHS.

Female Three Row 2-50 Pin Header Connector 2.0mm Pitch Board To Board PCB Connector

Female Three Row 2-50 Pin Header Connector 2.0mm Pitch Board To Board PCB Connector


Female Three Row 2-50 Pin Header Connector 2.0mm Pitch Board To Board PCB Connector


Female Three Row 2-50 Pin Header Connector 2.0mm Pitch Board To Board PCB Connector

Female Three Row 2-50 Pin Header Connector 2.0mm Pitch Board To Board PCB Connector

Female Three Row 2-50 Pin Header Connector 2.0mm Pitch Board To Board PCB Connector

Female Three Row 2-50 Pin Header Connector 2.0mm Pitch Board To Board PCB Connector


Our Quality

Except for the plating , also including design tools, stamping , Injection molding , assembly, Testing , and packing . All the steps are done by ourselves. So we can control the quality.


Service

good pre-sales & after-sales service &Strong technical support

1. New Project: Strong technical and ideal support for your new design
2. Existing projects: Try to help customers save costs to offer a good-quality product and save time.
3. Free Samples:3-5 PCS of each part number.
4. Customer complaint:24-48 hours reply 8D report.
5. Warranty: 24 months ( Merchandise is promised to be promptly returned, replacement,or repair kits if customers are not satisfied)
