SFP Port Connector Metal EMI Without Light Pipe Press-Fit Type 1X1 SFP Cage
SFP Port Connector Metal EMI Without Light Pipe Press-Fit Type 1X1 SFP Cage
SFP Port Connector Metal EMI Without Light Pipe Press-Fit Type 1X1 SFP Cage
SFP Port Connector Metal EMI Without Light Pipe Press-Fit Type 1X1 SFP Cage
SFP Port Connector Metal EMI Without Light Pipe Press-Fit Type 1X1 SFP Cage
SFP Port Connector Metal EMI Without Light Pipe Press-Fit Type 1X1 SFP Cage
Specifications
Gender :
Female
Features :
EMI Shielded
Mounting Type :
Through Hole
Packaging :
Tray
Termination :
Press-Fit
Brand Name :
XTK
Model Number :
SFP
Certification :
CE,SGS,ROHS,ISO9001
Place of Origin :
Guangdong,China
MOQ :
1pcs
Price :
Negotiable price
Payment Terms :
L/C,T/T,Payyal
Supply Ability :
1KK pcs
Delivery Time :
5-7 days
Packaging Details :
vacuum package,boxes in carton
Application :
PCB
Description

SFP / SFP+ 1×1 Cage Assembly Without Light Pipe – Metal EMI Shielded Press-Fit Connector, 20-Position Right-Angle Receptacle, Single-Port Hot-Swappable I/O for Switch / Media Converter / NIC PCB



Product Description

Parameter

Specification

Product Type

SFP / SFP+ 1×1 Cage Assembly with Integrated Receptacle

Form Factor

SFP (1.25G) / SFP+ (10.3125G) / SFP28 (25.78G) backward compatible

Port Matrix

1 × 1 (single port)

Positions

20

Pitch

0.8 mm (0.0315 in)

Mounting

Through-Hole, Right Angle

Termination

Press-Fit Compliant Pin (Ø0.64 mm, tail 2.05 / 3.0 mm) / optional SMT solder tail

Contact Material

Phosphor bronze

Contact Plating

Gold flash on mating area, tin on press-fit tail (30 µ" optional)

Cage Material

Copper alloy/nickel silver, nickel plated

Light Pipe

None​ (solid cage wall)

Heat Sink

Not included (heat-sink-compatible version optional)

EMI Feature

Internal + external beryllium-copper spring fingers

Data Rate

Up to 16 Gb/s (SFP+); 25G SFP28 supported by layout

Differential Impedance

100 Ω ±10%

Current Rating

0.5 A/contact @ 3.3 V

Contact Resistance

≤ 80 mΩ

Insulation Resistance

≥ 1000 MΩ @ 500 V DC

Withstand Voltage

300 V AC

Mating Cycles

≥ 100 (module hot-swap)

Insertion Force (module)

≤ 34 N

Extraction Force (module)

≤ 12.5 N

Operating Temp.

-55 °C to +105 °C (industrial build -40~+85 °C)

Housing Flame Rating

UL 94 V-0 (LCP)

Compliant

INF-8074i, SFF-8431, SFF-8402, RoHS 2.0, REACH

Cross Ref.

TE 2170039-1 / 2057159-1 / 2007198-1; Amphenol U77A1118200T; Molex 74737-0004

Typical Dimensions

L 48.6 × W 14.5 × H 9.4–12.1 mm

MOQ

500 pcs

Sample Lead Time

5–7 working days

Mass Lead Time

3–4 weeks

Packaging

Anti-static tray

SFP Port Connector Metal EMI Without Light Pipe Press-Fit Type 1X1 SFP Cage

Single-port SFP+ 1×1 cage without light pipe, full metal EMI shielding, press-fit 20-position receptacle, 0.8 mm pitch. Drop-in replacement for TE 2170039-1 / 2057159-1 / Amphenol U77A1118200T. Supports SFP/SFP+/SFP28 modules. Factory direct, MOQ 500 pcs, samples 5 days.
