Specifications
Brand Name :
Qingdao Zhenxiong
Model Number :
ZX-SZS
Certification :
ISO9001
Place of Origin :
Qingdao,China
MOQ :
1 set
Price :
58000 - 70000USD per set
Payment Terms :
L/C,T/T
Supply Ability :
20 sets per month
Delivery Time :
15 - 25 working days
Packaging Details :
After being wrapped with stretch film , it is shipped unpacked in the container .
Control System :
PLC
Voltage :
380V
Frequency :
50Hz
Power Source :
Electric
Description
Automatic Plastic Wire Making Machine for Broom Wire Production
Core Advantages
  • Professional reducer-equipped extruder with high-strength alloy steel components
  • 38CrMoAL/A screw and barrel material with nitriding treatment for durability
  • Air-cooled barrel with automatic temperature regulation
  • High-strength mold steel head mold with optimized structure for uniform wire output
  • Vertical plastic dehumidifying and drying machine with automatic controls
  • Overflow-type hot water tank for thorough wire heating
  • Helical gear-driven drawing machine for stable operation
  • Fully automated temperature control system with components
  • Automatic drying hopper and feeder to reduce labor costs
  • Double-station winding machine with adjustable wire collection racks
  • Water-cooled wire blanks for controlled crystallinity and elongation
  • Energy-saving oven with specially designed flow channel
Technical Specifications
Control System
PLC
Voltage
380V
Frequency
50Hz
Power Source
Electric
Weight
6T
Dimensions
32000×1500×2800mm
Warranty
12 months
Application Industries

Cleaning brushes, broom brushes, paint brushes, and similar wire-based products

Automatic Plastic Wire Making Machine Broom Wire Production Low Maintenance Automatic Plastic Wire Making Machine Broom Wire Production Low Maintenance
Product Description

Our high-automation plastic wire making machine is specifically designed for paint brush and broom wire production, featuring low maintenance requirements and exceptional durability. The equipment incorporates a professional reducer for the extruder, with gears and shaft components crafted from high-strength alloy steel through carburizing, quenching, and grinding processes. Oversized thrust bearings ensure high load-bearing capacity, stable transmission, and superior production efficiency.
