Single Screw Plastic Pipe Production Line Irrigation Water Supply Hose Pipe Making Machine
Single Screw Plastic Pipe Production Line Irrigation Water Supply Hose Pipe Making Machine
Single Screw Plastic Pipe Production Line Irrigation Water Supply Hose Pipe Making Machine
Single Screw Plastic Pipe Production Line Irrigation Water Supply Hose Pipe Making Machine
Single Screw Plastic Pipe Production Line Irrigation Water Supply Hose Pipe Making Machine
Single Screw Plastic Pipe Production Line Irrigation Water Supply Hose Pipe Making Machine
Single Screw Plastic Pipe Production Line Irrigation Water Supply Hose Pipe Making Machine
Single Screw Plastic Pipe Production Line Irrigation Water Supply Hose Pipe Making Machine
Specifications
Brand Name :
Kechengda
Model Number :
SJ-45 55 65 90
Place of Origin :
Qingdao,Shandong,China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
100
Delivery Time :
35 work days
Packaging Details :
wrapping film
Price :
USD18000-40000
Model NO. :
PE/HDPE Pipe
Usage :
Water Pipe, Electrical Pipe, Drain Pipe, Gas Pipe
Motor :
Simens Beide
Condition :
New
Temperature Control :
Omron
Raw Material :
PVC Powder and CaCO3
Automation :
Automatic
Production Speed :
Around 0.5-20meter/Minute
Description

Plastic Single Screw Extruder PE HDPE Irrigation Water Supply Energy Gas Hose Pipe Tube Extrusion Production Line

Product Description

Plastic Single Screw Extruder Double Three Triple ABA Layer PPR PE HDPE LLDPE LDPE Irrigation Water Supply Energy Gas Hose Pipe Tube Extrusion Production Line

PE pipe production line is primarily used in the manufacturing of PE pipes with diameters ranging from 16mm to 1200mm. The various thickness of the pipes produced can make them suitable for applications range from urban water supply to gas transportation. This line also excels in the production of anti-flammable and anti-static electricity pipes using a two- or three-layer spiral mold for use in mining industries. Pipes produced feature even wall-thickness and perfect roundness. Through switching or adding certain part of machine unit, this line can also be customized to extrude pipes of various other kinds.

Features

The optimum spiral structure-feeding throat highly improves the output of extruder;
Accurate temperature control system ensures materials melting performance;
Unique screw design achieves better plasticizing and high-quality products;
Precisely designed gearbox with a high torsion guarantees stable running;
"H" shape frame to decrease vibrating of extruder;
Advanced PLC operation system realizes synchronization and automation;
Adopt automatic water temperature & level control and special independent filters on both vacuum and cooling tanks;
Offer stable haul-off unit with 2-12 caterpillars;
Provide saw & chip-free cutting options;
Low energy consumption, excellent performance, and easy maintenance.

Conical Twin Screw Extruder
Specification/Model SJSZ45/90 SJSZ51/105 SJSZ65/132 SJSZ80/156 SJSZ92/188
Screw diameter 45/90 51/105 65/132 80/156 92/188
Ratitional speed of screw 1-45rpm 1-45.5rpm 1-38rpm 1-36.9rpm 1-34.5rpm
Main motor power 15kw 22kw 37kw 55kw 110kw
Barrel heating power 9.6kw 11.5kw 24kw 36kw 88kw
Production capacity 70kg/h 120kg/h 250kg/h 360kg/h 1000kg/h
Net weight 2500kg 3000kg 4000kg 5000kg 5500kg

Single Screw Extruder
Model NO. L/D Output Speed of Screw Rotationl Power Center Height
SJ-30 10-33 10-25kg/h 20-120r/min 3-5.5kw 1000mm
SJ-45 10-33 10-35kg/h 20-120r/min 7.5-18.5kw 1000mm
SJ-50 10-33 20-80kg/h 20-120r/min 22-37kw 1000mm
SJ-65 10-33 80-150kg/h 20-120r/min 37-55kw 1000mm
SJ-75 10-33 120-280kg/h 20-120r/min 55-90kw 1000mm
SJ-90 10-33 150-450kg/h 20-120r/min 90-160kw 1200mm
SJ-120 10-33 300-600kg/h 20-120r/min 160-260kw 1200mm
SJ-150 10-33 450-700kg/h 20-120r/min 260-315kw 1200mm

Single Screw Plastic Pipe Production Line Irrigation Water Supply Hose Pipe Making MachineSingle Screw Plastic Pipe Production Line Irrigation Water Supply Hose Pipe Making MachineSingle Screw Plastic Pipe Production Line Irrigation Water Supply Hose Pipe Making MachineSingle Screw Plastic Pipe Production Line Irrigation Water Supply Hose Pipe Making Machine
