Fully Automatic Plastic Soft Pipe Hose Coiler Machine Tube Winder Machine
Fully Automatic Plastic Soft Pipe Hose Coiler Machine Tube Winder Machine
Fully Automatic Plastic Soft Pipe Hose Coiler Machine Tube Winder Machine
Fully Automatic Plastic Soft Pipe Hose Coiler Machine Tube Winder Machine
Fully Automatic Plastic Soft Pipe Hose Coiler Machine Tube Winder Machine
Fully Automatic Plastic Soft Pipe Hose Coiler Machine Tube Winder Machine
Fully Automatic Plastic Soft Pipe Hose Coiler Machine Tube Winder Machine
Fully Automatic Plastic Soft Pipe Hose Coiler Machine Tube Winder Machine
Fully Automatic Plastic Soft Pipe Hose Coiler Machine Tube Winder Machine
Fully Automatic Plastic Soft Pipe Hose Coiler Machine Tube Winder Machine
Specifications
Brand Name :
Kechengda
Model Number :
SJ-32
Place of Origin :
Qingdao,Shandong,China
MOQ :
1
Price :
USD 32000~80000
Payment Terms :
T/T
Supply Ability :
100
Delivery Time :
35 work days
Packaging Details :
wrapping film
Condition :
New
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Warranty of core components :
1 Year
Core Components :
PLC, Motor
Weight :
800
Warranty :
1 Year
Key Selling Points :
Competitive Price
Applicable Industries :
Manufacturing Plant
Application :
Pipe winding
Inside Diameter Range :
3-39mm
Outside Diameter Range :
4-40mm
Spool Capacity :
2000m
Arrange Width :
50-600mm
Voltage :
380V
Power :
6750
Dimension(L*W*H) :
3m*1m*2m
Description
Product Description
This machine is used to wind all kind plastic pipes automatically cutting and changing the bobbins without stopping. It could save lots of manpower and decrease the production cost.
1. Machine components:
* Laser tension regulator
* Tube leading device
* Auto-spool position changing system
* Auto precise traverse arranging system
* Double position winding plate
* Electric control system

2. Technical specification:
Height of tube entry:1100mm, adjustable
Structure type:Two same specification winding devices on same side;Shaft + spool type winding unit;
Specification of spool: Max out diameter 1600mm,Max width 600mm adjustable.
Leading device:SUS304 roller guide pillar with internal built-in self-lubricating bearing.
Auto-spool position changing:When one spool is full, auto clamping and cutting tube, auto leading onto another spool.
Humanized design, cutting blade can be changed quickly.
Traverse arranging:Traverse arranging distance 0-600mm, traverse arranging sliding rail is precision ball screw, driven by servo motor, optical fiber sensor control traverse arranging reversing.
Traverse arranging motor:“Co-Trust” servo motor/driver, 0.75KW × 1set
Winding motor:“Co-Trust” servo motor/driver, 3.0KW × 2sets
Winding line speed:Max.80m/min.
Length counting: Meter counter installed in the first group of leading rolling wheel group, adopt contact type meter counting wheel and rotary encoder counting mode, when the winding length close to the requires, it will alarm with sound and light, and accuracy of the length counting ≤0.1%.
Tube/wire specification:Tubing, DN 4 - 40mm

3. Working performance:
Tube/Wire winding on plate uniformly under no stretching status. No cross overlapping phenomenon. Arrange Orderliness.
Specification
item
value
Place of Origin
China
Brand Name
Qingdao Kechengda Plastic Machine
Application
Pipe winding
Condition
New
Video outgoing-inspection
Provided
Machinery Test Report
Provided
Warranty of core components
1 Year
Core Components
PLC, Motor
Inside Diameter Range
3-39mm
Outside Diameter Range
4-40mm
Spool Capacity
2000m
Arrange Width
50-600mm
Voltage
380V
Power
6750
Dimension(L*W*H)
3m*1m*2m
Weight
800
Warranty
1 Year
Key Selling Points
Easy to Operate
Applicable Industries
Manufacturing Plant
