Specifications
Brand Name :
Dingzhi
Model Number :
DZ-TPE80A
Certification :
Reach,ISO
Place of Origin :
China
MOQ :
25kg
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
700Tons/ Month
Delivery Time :
3-5 working days
Packaging Details :
Waterproof bag, 25KG per bag
Material :
TPE
Hardness :
86-88A
Color :
Transparent
Description

Medical-Grade TPE Food-Grade TPE Material Soft Touch Easy To Process Weather Resistance Chemical Resistance

Production Process:

Drying material requirements: Please dry at 90-100℃ for 3-4 hours;
Injection molding temperature: 165-170 degrees for the first section, 175-190 degrees for the second section, and 175-185 degrees for the third section.
Pressure: 75-110 Pa

Features:

  • Excellent elasticity and soft touch: Provides a comfortable feel and cushioning effect.
  • Easy to process: Can be efficiently produced using plastic processing equipment (such as injection molding and extrusion), with short processing cycles and recyclable waste.
  • Design freedom: Easy to color (rich and vibrant colors) and overmold (strongly bonded to hard plastics such as PP, ABS, PC, and PA, creating "soft-hard" two-color or multi-color products).
  • Weather resistance: Some TPEs offer excellent resistance to UV rays, ozone, and extreme temperatures.
  • Chemical resistance: Excellent resistance to water, alcohols, weak acids, and weak bases.
  • Environmental friendliness: Recyclable and reusable, with some formulations being biodegradable (depending on the formulation).
  • Safety: Can meet stringent safety and regulatory requirements, including those for medical and food grade applications.

Technical Datasheet

Model:DZ-TPE80A
Material: TPE Processing method: Injection molding
Test Items Test method Test Unit Test Results
Hardness ISO R 868 Shore 86-88A
Specific Gravity ASTM D-792 g/cm³ 0.91
Tear strength ASTM D-624 kN/m 76.47
Tensile strength ASTM D-412 Kg/cm2 84.27
Breaking elongation ASTM D-412 % 274.3
100% modulus ASTM D-412 Kg/cm2 66.87
Anti-UV/anti-yellowing Solar lamp 300W/50 degrees/24hrs 2
Transparency Visual inspection of ladder test piece semitransparent
Production Process:
Drying material requirements: Please dry at 90-100℃ for 3-4 hours;
Injection molding temperature: 165-170 degrees for the first section, 175-190 degrees for the second section, and 175-185 degrees for the third section.
Pressure: 75-110 Pa

Applications

Widely use in cables, electronic accessories.

Medical-grade TPE: Meets biocompatibility requirements and is used to manufacture infusion tubes, respiratory masks, suction bulbs, medical catheters, seals, artificial prosthetic parts, pharmaceutical packaging, etc.

Food-grade TPE: Meets food safety regulations and is used to manufacture food processing equipment seals, conveyor belts, tableware, drinking tubes, nipples, water cup nozzles, food packaging seals, etc.

Dingzhi Polymer provide wide range of raw material, can be widely used in shoe materials, bag materials, sports equipment, medical equipment, the automobile industry, packaging products, wire and cable coating materials, hoses, films, coatings, inks, adhesives, melt spun spandex fibers, artificial leather, bonded clothing, gloves, air blowing products, agricultural greenhouse, air transportation, and national defense industry.

Please contact us for details.
