Battery Impact Test Machine UL 1642 Compliant 9.1kg Drop Weight
Battery Impact Test Machine UL 1642 Compliant 9.1kg Drop Weight
Battery Impact Test Machine UL 1642 Compliant 9.1kg Drop Weight
Battery Impact Test Machine UL 1642 Compliant 9.1kg Drop Weight
Battery Impact Test Machine UL 1642 Compliant 9.1kg Drop Weight
Battery Impact Test Machine UL 1642 Compliant 9.1kg Drop Weight
Battery Impact Test Machine UL 1642 Compliant 9.1kg Drop Weight
Battery Impact Test Machine UL 1642 Compliant 9.1kg Drop Weight
Battery Impact Test Machine UL 1642 Compliant 9.1kg Drop Weight
Battery Impact Test Machine UL 1642 Compliant 9.1kg Drop Weight
Specifications
Brand Name :
Sinuo
Model Number :
SN555-432L
Certification :
Calibration Certificate (Cost Additional)
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
10 Sets Per Month
Delivery Time :
30 Days
Packaging Details :
Export packing
Test Room :
W1200 X D600 X H600mm
Air Vent :
150mm
Viewing Window Size :
390 X 360mm
Drop Ball Weight :
9.1kg
Dropping Height :
0~880mm
Control Method :
PLC Control
Crossing Bar Diameter :
15.8 mm
Chamber Size :
W1840 X D1080 X H2220mm
Description

Battery Heavy Impact Test Machine Battery Impact Resistance Testing UL 1642

Complied Standards & Clauses

The product must meet below test standards and referred tests;

-UN 38.3 “Impact Test”

-UL 1642 “Impact Test”

-IEC 62281 “Impact Test”

-UL 1973 “Impact Test”

-IEC 62619-2017 “Impact Test”

Product Overview

The test sample battery is placed on a flat surface, and a rod with a diameter of 15.8 ± 0.2 mm (5/8 inch) is crossed and placed in the center of the sample. A 9.1kg or 10kg weight falls from a certain height (610mm or 1000mm) onto the sample. When a cylindrical or square battery undergoes an impact test, its longitudinal axis should be parallel to the plane and perpendicular to the longitudinal axis of the steel column. The longest axis of the square battery is perpendicular to the steel column, the largest face is perpendicular to the direction of impact, and each battery is subjected to only one impact test. The battery does not catch fire and does not explode as qualified.

Technical Parameters

Drop Ball Weight 9.1kg
Dropping Height 0~880mm (The heavy can raise to a height and release to ensure the heave drop free without incline and swing)
Control Method PLC Touch Screen Control+ Remote Control
Crossing Bar Diameter 15.8 mm (Place on central position in cross direction and the heavy bar and steel bar is parallel to battery bottom)
Test Room W1200 X D600 X H600mm
Internal Material SUS 304# Stainless steel(thickness 1.0mm compensation and external chamber thickness 80mm)
External Material Cool-Rolled Plate (thickness 1.0mm)
Air Vent 150mm, on the top of back of chamber
Chamber Gate Single Door, Viewing Window, cold-rolled door lock
Viewing Window Size 390 X 360mm (20mm Dual layer glass explosion proof film)
Elevating Method Motorized
Top/bottom impact surface Steel Plate
Chamber Size W1840 X D1080 X H2220mm
Power Source AC 220V, 60Hz
Power 2.0KW
Gross Weight About 350KG
Touch Screen Monitoring Battery Impact Test Machine UL 1642 Compliant 9.1kg Drop Weight
Video Monitor
Brand MI
Model MJSXJ09CM
Size 115*78*78mm
Resolution 1296P(3 megapixel)
Viewing angle Horizontal 360° Vertical 108°
PTZ control APP control (Horizontal + Vertical)
Full color night market Low light full color
Infrared night vision Support
Two-way voice Support
Tracking function Support
Install method lay flat /upside down /side mounted
Wifi channel 2.4GHz
Storage Come with 32G microSD card

Details

Battery Impact Test Machine UL 1642 Compliant 9.1kg Drop WeightBattery Impact Test Machine UL 1642 Compliant 9.1kg Drop Weight
