Specifications
Brand Name :
Sinuo
Model Number :
SN552-30V200A
Certification :
Calibration Certificate (Cost Additional)
Place of Origin :
China
MOQ :
1
Price :
Customized
Payment Terms :
T/T
Supply Ability :
1 sets/month
Delivery Time :
30 days
Packaging Details :
Plywood Case
Discharge voltage range :
8V~60V
Charging voltage range :
0V~60V
Minimum output current :
±300mA
Maximum output current :
±120A
Current conversion time :
≤40ms
Current start response time :
≤20ms
Channel action mode :
Fully independent
Number of main channels :
2 Channels
Description
Battery Overcharge & Over-Discharge Test Equipment
High-Precision Battery Pack Testing System - 60V 120A Lithium Battery Testing Life Cycle Tester
Equipment Overview
This feedback-type high-precision battery pack detection equipment enables comprehensive testing of lithium-ion battery performance indicators including capacity, state of charge, overcharge, and over-discharge capabilities.
  • High power, efficiency, precision, and performance characteristics
  • Electric energy feedback technology significantly reduces heat emission and power consumption
  • Composed of host computer, middle computer, DC/AC module, DC/DC module, lower computer, and data acquisition system
  • Real-time collection of voltage, current, capacity, and energy data for individual battery cells
  • Optional battery temperature data collection capability
  • Specialized database storage with comprehensive data statistics, analysis, and report generation
Technical Parameters
Channel Configuration
Number of Main Channels2 Channels
Channel Action ModeFully Independent
Main Channel Working Modes
Charging: Constant Current Charging (CC), Constant Voltage Charging (CV), Constant Current Constant Voltage Charging (CCCV)
Discharging: Constant Current Discharge (CD), Constant Power Discharge (CP), Constant Voltage Discharge
Other: Standing, Stopping
Main Channel Specifications
ParameterSpecification
Test Termination ConditionsTime, Voltage, Current, Capacity
Voltage Range (Charging)0V~60V
Voltage Range (Discharging)8V~60V (8V device port voltage)
Voltage Accuracy±(0.05%RD+0.05%FS)
Voltage Resolution0.1mV
Maximum Output Current±120A
Minimum Output Current±300mA
Current Accuracy±(0.05%RD+0.05%FS)
Current Resolution0.1mA
Current Start Response Time≤20ms
Current Conversion Time≤40ms
Time Resolution1000mS
Power & Efficiency
ParameterSpecification
Output PowerMaximum 7200W per channel continuous operation
Stability±0.1%FS
Highest Charging Efficiency85%
Highest Discharging Efficiency85%
Harmonic≤3%
Power Factor≥0.99
Additional Features
Auxiliary Channel CutoffMain channel step stop/switch based on auxiliary channel conditions
Communication MethodRJ-45 network interface for stable, real-time long-distance data collection
