Specifications
Brand Name :
Energy Splendor
Model Number :
ES-AFDC120-01
Certification :
CE Certified
Place of Origin :
China
MOQ :
1
Price :
USD3176/pcs
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 pieces per months
Delivery Time :
20days
Packaging Details :
carton
Product name: :
EV DC Charging Station
Input Voltage: :
200-750V
cooling method :
Air-cooled
Protection level: :
IP65
Display: :
7inch Touch Screen
Networking Mode: :
Ethernet, 4G, wifi,APP Control mini program
Interface Standard: :
IEC,SAE,GB/T,CHAdeMo
Output Power: :
60-180KW, 120KW Dual Gun Max
Input Voltage Range: :
200V~750V
Connector: :
CCS2/CCS1/GBT/CHAdeMO
Efficiency: :
95%
OCPP: :
1.6
Description

30kw 60kw 120kw 180kw Electric Vehicle Public CCS Chademo OCPP Dc Fast EV Charging Stations For Bus

PRODUCT PARAMETER

ES-DC series outdoor DC integrated charger adopts a new generation of intelligentcharging module single and double output can be selected according to customerrequirements.The dual-gun type can be distributed according to the actual chargingdemand to meet the charging needs of small and medium-sized passenger cars andlogistics vehicles. lt is easy to install, stable in performance, and provides completeprotection function. The LCD display can show the charging status, user friendly. ltsupports 2G/4G/WiFi/Ethernet/Mini-program communication with party system forremote monitoring/maintain/upgrade. The charger can optionally equip with a columnsupport installed outdoors.

Our DC fast ev chargers support Management Software,Security Protection,IP54 design forharsh environment,Multiple payments,CE/DAKKS certificate,Customized Brand and Painting support.

Electric vehicles (EVs) are becoming more and more popular as people seek cleaner and more sustainable transportation solutions. However, one of the biggest challenges facing EV owners is finding a reliable and convenient place to charge their vehicles. That's where the 180kW EV charging station comes in. Our product is designed to provide fast, reliable, and convenient charging for EV owners, whether they are on the go or at home.

With a power output of 180kW, our charging station is capable of delivering a high-speed charge to any compatible EV, allowing drivers to get back on the road quickly with minimal downtime. Our charging stations utilize the latest in charging technology to provide a safe and efficient charging experience, ensuring that EV owners can charge their vehicles with complete peace of mind.

We believe that the future of transportation is electric, and we are committed to providing the infrastructure necessary to support this transition. Our 180kW EV charging station is just one example of the products and services we offer to help make EV ownership more accessible and convenient for everyone.

DATASHEET

Product Integrated Dc Chariging Station
Type 120KW 160KW 180KW
Dimensions 720*557*1700 (mm)
HCI(Human-computer intersaction) 7 inch touch screen
AC power 380Vac+15%;50HZ+10%;L1+L2+L3+N+PE
Rating Current 250-280A
Power Output Rating 120KW 160KW 180KW
Environmental Elevation: ≤2000m; Temperature: -20°C~+50°C;
Charging Mode Swipe card, Scan code
Networking Mode 4G,Wifi,Bluetooth,Ethernet
Operating Pattern noncharge offline,charge offline, charge online
Protection Function Over voltge; under voltage; over load; short circuit; earth leakage; ground protection surge protection, etc.
Connector Type CCS1, CCS2,CHAdeMO, GB/T
Charging Cable Length 5m(customizable)
Protection Grade Ip54

Public CCS Chademo OCPP Dc Fast EV Charging Stations 30kw 60kw 120kw 180kw For Bus

Public CCS Chademo OCPP Dc Fast EV Charging Stations 30kw 60kw 120kw 180kw For BusPublic CCS Chademo OCPP Dc Fast EV Charging Stations 30kw 60kw 120kw 180kw For BusPublic CCS Chademo OCPP Dc Fast EV Charging Stations 30kw 60kw 120kw 180kw For BusPublic CCS Chademo OCPP Dc Fast EV Charging Stations 30kw 60kw 120kw 180kw For BusPublic CCS Chademo OCPP Dc Fast EV Charging Stations 30kw 60kw 120kw 180kw For Bus

OUR SERVICE

Customer Service

1.We can provide customers with professional product advice and purchase options.

2. All emails will be responded within 24 hours during working days.

3. All customers will get one-on-one service.

Delivery Time

1.Samples or test orders can be delivered within 2-5 working days.

2.Orders in standard products above 100pcs could be delivered within 7-15 working days.

3.Orders that require customization could be produced within 20-30 working days.

Customized Service OEM&ODM

1.We provide flexible customized services with our abundant experiences in kinds of OEM and ODM projects.

2.OEM includes color, length, logo, packaging, etc.

3.ODM includes product appearance design, function setting, new product development, etc.

4.MOQ is depend on different customized requests.

After Sale Service

1.The warranty of all our products is one year. The specific after-sale plan will be free for replacement or charging a certain maintenance cost according to the specific situations.

2.However, according to the feedback from markets, we seldom have after-sale problems because strict product inspections are carried out before leaving the factory.
