143kWh BESS High Voltage LiFePO4 Battery Outdoor Energy Storage System
143kWh BESS High Voltage LiFePO4 Battery Outdoor Energy Storage System
143kWh BESS High Voltage LiFePO4 Battery Outdoor Energy Storage System
143kWh BESS High Voltage LiFePO4 Battery Outdoor Energy Storage System
143kWh BESS High Voltage LiFePO4 Battery Outdoor Energy Storage System
143kWh BESS High Voltage LiFePO4 Battery Outdoor Energy Storage System
143kWh BESS High Voltage LiFePO4 Battery Outdoor Energy Storage System
143kWh BESS High Voltage LiFePO4 Battery Outdoor Energy Storage System
Specifications
Place of Origin :
China
Battery Type :
LiFePO4
System Cooling Method :
Air Cooling
Waterproof Rating :
IP55
Cycle Life :
≥10000 Cycles (25°C±2°C,0.35C,80%DOD@65%EOL)
System Rated Voltage (V) :
512
Net Weight(kg) :
~1615
System Nominal Energy(kWh) :
143.36
Packaging Details :
Different packaging methods are adopted according to different modes of transportation
Maximum Size(mm) :
1395*1080*1850
Price :
Negotiable
Module Nominal Energy(kWh) :
51.2
Payment Terms :
L/C, T/T, DDP, DDU
Brand Name :
EUE Power
Rated Capacity(Ah) :
280
MOQ :
10 pcs
Product Name :
G-CUBE 143kWh Battery Outdoor Energy Storage System
Description

G-CUBE 143kWh Battery Outdoor Energy Storage System

This industrial-grade energy storage system features a plug-and-play design for fast installation and high energy density to optimize space. Equipped with an intelligent BMS for accurate SOC and stability, it includes integrated air conditioning and fire protection systems. It supports flexible parallel operation and offers a service life of over 10 years.

  • Fast Installation: Plug-and-play design.
  • Space Efficient: High energy density.
  • Intelligent Management: Accurate SOC and stability via BMS.
  • Integrated Safety: Built-in air conditioning and fire protection.
  • Longevity: Over 10 years service life.

Product Advantages

  • Smart BMS

    Intelligently identify the master-slave batteries auto DIP address

  • Easy maintenance

    Compact and lightweight for easy installation

  • Deep Cycle

    ≥8000 Cycles (25℃±2℃, 0.5C, 80% DOD @65% EOL)

  • Warranty

    Up to 5 years

Product Features

Plug and play

The system adopts a plug-and-play design, making installation and commissioning faster and more convenient.

High energy density

With high energy density, the system helps reduce transportation costs and save installation space.

Safer installation

The design reduces installation risks for operators and improves overall product stability.

Intelligent BMS management

The intelligent BMS provides continuous cell balancing, keeping SOC more accurate, improving cell consistency and ensuring a system service life of more than 10 years.

Integrated safety system

The system integrates air conditioning and fire protection systems to improve stability and operational safety.

Flexible parallel operation

The system supports multi-unit parallel operation with AC coupling. When connected to the grid, the number of parallel units is not limited. For off-grid parallel operation, fewer than 4 units are supported, depending on the customer’s off-grid load type and load power.

Product Photos

143kWh BESS High Voltage LiFePO4 Battery Outdoor Energy Storage System
143kWh BESS High Voltage LiFePO4 Battery Outdoor Energy Storage System
143kWh BESS High Voltage LiFePO4 Battery Outdoor Energy Storage System
143kWh BESS High Voltage LiFePO4 Battery Outdoor Energy Storage System

Technical Parameters

MODEL G-CUBE 143KWHB
Battery Type LiFePO4
Module Nominal Energy(kWh) 14.336
Module Nominal Voltage(V) 51.2
Rated Capacity(Ah) 280
No. of System Module SeriesConnections 10
System Rated Voltage (V) 512
System Operating Voltage(V) 448~576
System Nominal Energy(kWh) 143.36
System Discharge Energy (kWh) 137.63
Charge /Discharge Current(A) Rated Current 140
Max. Current 150
Overload Current 155(10 sec,25°C)
Status Indicator Light Blue: PCS system working status, green: battery system running status, red: battery system fault status
Communication Protocol CAN2.0
Operating Temperature Range(C ) -10~55
Operating Humidity Range ≤95%(No Condensation)
Operating Alitude ≤2000m
System Cooling Method Air Cooling
Waterproof Rating IP55
Fire Fighting System Hot aerosol
Net Weight(kg) ~1615
Maximum Size(mm) 1395*1080*1850
Storage Temperature(C) 0~35
Recommended Depth ofDischarge(DOD) 90%
Cycle Life ≥10000 Cycles (25°C±2°C,0.35C,80%DOD@65%EOL)
System Composition BMS management system, fire protection system, air-cooled unit, cabinet, PCS system
Certification Cell:UL1973/EC62619/UL9540A/TUV/CE/MSDS/UN38.3
Warranty 5 Years(Under Warranty Terms)
Energy Throughput “1” 313MWh

About EUE Power – Your Trusted Power Distribution Equipment Manufacturer

EUE Power is a China-based manufacturer specializing in power distribution equipment and energy storage products for global industrial, commercial, and renewable energy applications.

With professional manufacturing capabilities and OEM/ODM support, EUE Power supplies reliable power distribution products including distribution transformers, compact substations, switchgear, UPS systems, and battery energy storage systems.

Our factory combines engineering expertise, strict quality control, and flexible production capabilities to meet different market requirements worldwide.

Whether you are looking for a reliable distribution transformer supplier, compact substation manufacturer, switchgear supplier, or energy storage equipment partner, EUE Power provides dependable products and professional support.

Partner with EUE Power for:

  1. Stable manufacturing quality
  2. Customized OEM/ODM services
  3. Competitive factory pricing
  4. International export experience
  5. Professional technical support

EUE Power — Reliable Power Equipment Manufacturer for Global Markets.
