Indoor 8 Core Fiber Optic Cable , Single Mode Fiber Optic Light Cable PVC LSZH
Indoor 8 Core Fiber Optic Cable , Single Mode Fiber Optic Light Cable PVC LSZH
Indoor 8 Core Fiber Optic Cable , Single Mode Fiber Optic Light Cable PVC LSZH
Indoor 8 Core Fiber Optic Cable , Single Mode Fiber Optic Light Cable PVC LSZH
Indoor 8 Core Fiber Optic Cable , Single Mode Fiber Optic Light Cable PVC LSZH
Indoor 8 Core Fiber Optic Cable , Single Mode Fiber Optic Light Cable PVC LSZH
Specifications
Brand Name :
BLG / OEM / ODM
Model Number :
BULK FIBER OPTIC CABLE
Certification :
CE / ROHS / ISO
Place of Origin :
CHINA
MOQ :
5000 Meters
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10000 Kilometers per Week
Delivery Time :
10 - 15 Work Days
Packaging Details :
5000 Meters / Wooden Drum
Model: :
1~12 Core
Fiber Type :
Singlemode
Jacket :
PVC / LSZH
Storage Temperature :
-40 °C ~ +80 °C
Length :
1000M / 2000M per roll
Application :
Telecommunication
Description

Indoor 8 Core Bulk Fiber Optic Cable Single Mode PVC LSZH USE Indoor

Bulk Fiber Optic Cable Construction

Number of fiber 8core
Loose tube material PBT
diameter 2.2 ( outer / inner )
Tube - filling Tube filling compoun
Steel wire size 0.8mm
Number 2
Outer sheath material PE, HDPE, LDPE
diameter 1.8 ± 0.2mm

Bulk Fiber Optic Cable Mechanical Characteristic

Core Cable diameter weight
1~8 8.0mm + / - 0.3mm 65kg / km + / - 10kg
Temperature range -40 ~ +70 ( ℃ ) -----
Min Bending Radius(mm) Long term 10D
Min Bending
Radius(mm)		 Short term 20D
Min allowable
Tensile Strength(N)		 Long term 1200
Min allowable
Tensile Strength(N)		 Short term 1500
Operation temperature -40 ~ +70 ( ℃ )
Installation temperature -20 ~ +60 ( ℃ )
Storage temprature -40 ~ +70 ( ℃ )

Indoor 8 Core Fiber Optic Cable , Single Mode Fiber Optic Light Cable PVC LSZH

Bulk Fiber Optic Cable Features
1. Tight buffer fiber ease of stripping.
2. The jacket anti-corrosion, anti-water, anti-alltraviolet ratardation, flame retardant and harmless to environment etc;
3. Excellent flame retardart jacke and anti-torsion;
4. Soft, flexible, easy to splice, and with big capacity data transmission;
5. Excellent performance of anti-torsion;
6. All dielectric structure protect it from electromagnetic influence;

Bulk Fiber Optic Cable Application
1. Multi optical fiber jumper, patch cord, pigtail cable;
2. Indoor any purpose cable distribution
3. Backbone building distribution cabling.

4. Installation: wall, interlayer, pipe, trough, duct.

Indoor 8 Core Fiber Optic Cable , Single Mode Fiber Optic Light Cable PVC LSZH

Indoor 8 Core Fiber Optic Cable , Single Mode Fiber Optic Light Cable PVC LSZH

Indoor 8 Core Fiber Optic Cable , Single Mode Fiber Optic Light Cable PVC LSZHIndoor 8 Core Fiber Optic Cable , Single Mode Fiber Optic Light Cable PVC LSZH

Bulk Fiber Optic Cable Specification

Fiber count Cable Diameter (mm) Cable Weight (kg/km)

Tensile (N)

Long/ Short term

Crush (N/100mm)

Long/ Short term

Min. Bend Radius (mm)

Dynamic/ Static
4 5.0 19.0 130/440 200/1000

20D/10D
6 5.2 23.0 130/440 200/1000
8 5.5 26.0 130/440 200/1000
12 6.5 36.5 200/660 200/1000
16 7.5 44.5 200/660 200/1000
24 8.2 54.5 200/660 200/1000

Note:

1. The min. bend radius (static) is 5D when G657 fiber is used.

2. Range of temperature: -40 ~ +70 °C

3. D is outer diameter of the round cable

4. Tight-buffered fiber is 0.9mm
