Specifications
Brand Name :
TengTian
Model Number :
114
Certification :
CE, ISO9001, BV
Place of Origin :
Hebei
MOQ :
1 Set
Price :
$100000 to $1 million
Payment Terms :
L/C,T/T,D/A,T/T
Supply Ability :
4 Sets/Year
Delivery Time :
300 work days
Packaging Details :
Export waterproof and Seaworthy packing.
Product name :
High Frequency Welded Pipe Mill 114Mm Quick Change Roller High Frequency Welded Pipe Mill Straight Seam Steel
Equipment Specification :
high frequency and precision
Forming method :
Roller Squeeze
Warranty :
One year
Pipe material :
Steel
Pipe shape :
round and square
Thickness :
1 . 5 mm - 5 . 0 mm
Pipe diameter :
45 - 114
Raw material :
steel
Key words :
High Frequency Welded Pipe Mill
Description

Straight Seam Steel 114 Mm Quick Change Roller Pipe Making Mill Equipment High Frequency Welded Pipe Mill

114 Mm Quick Change Roller Pipe Making Mill Equipment High Frequency Welded Pipe Mill Production Introduction and Process

114 high frequency welded pipe mill line is used to manufacture welded steel pipe.After we absorbed advanced pipe making technology from both abroad and domestic, our innovative designed production line and each single unit of the production line is not only economical but also practical.

Pipe size: 76 - 114 mm Pipe thickness: 1.5 - 4 . 0 mm

Loading car → Uncoil → Flattening → End Shear & Butt Welding → Accumulator → Forming → High-frequency induction welding→ Removing external burr → Cooling → Sizing → Cutting → Layout table

114 Mm Quick Change Roller Pipe Making Mill Equipment High Frequency Welded Pipe Mill Equipment composition

No. Name
1 Uncoiler
2 Straightener & leveler
3 Automatic shear and welding
4 Feeder and punching machine
5 Automatic forming and sizing part
6 Cutting machine
7 Packing and palletizing

114 Mm Quick Change Roller Pipe Making Mill Main Parameters and Specifications:

⑴ Material Specifications:

Material low carbon steel galvanize and crabon steel tube
Mechanical properties σb≤520Mpa,σs≤340MPa
strip width 230 - 360 mm
strip thickness 1 . 5 - 4 . 0 mm
I.D of Coils 520 - 580 mm
O.D of Coils 1000 - 1600 mm
Coil Weight ≤ 7T

⑵ Welded Pipe Specification

Pipe Diameter Φ 76~ φ 114 mm
pipe thickness 1 . 5 - 4 . 0 mm
Finish pipe length 4 - 6 m
Cut length accuracy ± 3 mm
Forming speed 40 - 50 m/min

(3)Power, Water & Air Supply

1 Power Power Volume of the Line Approx.800KW
Power Source 415V/50Hz/3phases
2 Circulation Cooling Water Flow 30T/h~40 T/h
Pool Volume 60m3
3 Compressed Air Flow 5m3/min
Pressure 5~7kg/ cm2

(4) workshop require : 100 m X 6 m ,at least 5m high

Notice:You can modify it according to the actual length of the workshop
