High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm
High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm
High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm
High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm
High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm
High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm
High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm
High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm
High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm
High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm
Specifications
Brand Name :
Tengtian
Model Number :
HG32
Certification :
CE,ISO9001,BV
Place of Origin :
Hebei,china
MOQ :
1 Set
Price :
$100000 to $1 million
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
30 Sets
Delivery Time :
120 work days/Year
Packaging Details :
Export waterproof and Seaworthy packing.
Production Name :
High Frequency Welded Pipe Mill Erw Carbon Steel Pipe Roll Forming Welded Pipe Mill High Frequency
Material :
HRC,CRC
Pipe diamete :
12-32 mm
pipe thickness :
0.4-1.5mm
Welding Type :
H.F solid welder
Pipe shape :
Round,square,rectangular
Roller materoal :
Cr12/SKD11
Key words :
high frequency welded pipe mill
Description

Erw Carbon Steel Pipe Roll Forming High Frequency Welded Pipe Mill

Product Description:

Erw Carbon Steel Pipe Roll Forming High Frequency Welded Pipe Mill is used to manufacture round/square welded steel pipe.After we absorbed advanced pipe making technology from both abroad and domestic, can product different size,shape tube and ensure the tube precision.

Round pipe size: 12--32mm Pipe thickness: 0.4-1.5mm

square tube size:10x10-20x20mm, tube thickness:0.4-1.5mm

Main Parameters and Specifications:

Material Specifications

  • Conforming to the YB189-64 standard
  • steel material: Q235/Q345
  • Mechanical properties:σb≤380Mpa,σs≤275MPa
  • strip width:37-100MM
  • strip thickness:0.4-1.5MM
  • I.D of Coils:Φ508mm
  • O.D of Coils:φ1800mm
  • Coil Weight:2.5TON

Welded Pipe Specification

  • Round Pipe Diameter:Φ12～φ32mm
  • square tube size:10X10-20X20MM
  • pipe thickness:4.0-8.0MM
  • Finish pipe length:6-12M
  • Forming speed:40-120M/MIN

workshop require

6m wide, 60m long, at least 5m high from Ceiling Rails to Ground.

ERW Tube Mill Other Model

Model Diameter Range Pipe Thickness Line Speed(m/min)
HG20 8-25.4MM 0.3-1.2MM 120
HG32 10-32MM 1.4-1.5MM 120
HG50 16-76MM 0.7-2.5MM 30-120
HG76 25-76MM 1-4MM 30-100
HG89 32-89MM 1-4.5MM 30-80
HG114 45-114MM 1.5-5.0MM 30-60
HG165 60-165MM 3-7MM 30-50
HG219 114-219MM 4-8MM 20-40
HG273 114-273MM 4-10MM 15-30
HG325 165-325MM 4-10MM 10-30
HG426 165-426MM 4-12.7MM 8-25
HG508 219-508MM 4-16MM 8-20

High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm

High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm

High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm

High Frequency Welded Pipe Mill for ERW Carbon Steel Pipes 12-32mm
