High Frequency Welded Pipe Mill 80x80-200x200mm 4-10mm Thickness
High Frequency Welded Pipe Mill 80x80-200x200mm 4-10mm Thickness
High Frequency Welded Pipe Mill 80x80-200x200mm 4-10mm Thickness
High Frequency Welded Pipe Mill 80x80-200x200mm 4-10mm Thickness
Specifications
Brand Name :
Tengtian
Model Number :
HG200x200
Certification :
CE,ISO9001,BV
Place of Origin :
Hebei,CHINA
MOQ :
1 Set
Price :
$100000 to $1 million
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
30 Sets
Delivery Time :
180 work days
Packaging Details :
Export waterproof and Seaworthy packing.
Production Name :
High Frequency Welded Pipe Mill 200x200mm Automatic Steel Pipe
Material :
HRC,CRC,Galvanised Steel
Pipe size :
80x80-200x200mm
pipe thickness :
4.0-10.0mm
Welding Type :
High Frequency Welding
Pipe shape :
Round,square,rectangular
Roller materoal :
Cr12/SKD11
Key words :
high frequency welded pipe mill
Description

Automatic Steel Pipe 200x200mm High Frequency Welded Pipe Mill

Product Description:

Automatic Steel Pipe 200x200mm High Frequency Welded Pipe Mill is used to manufacture welded steel pipe.After we absorbed advanced pipe making technology from both abroad and domestic, can product different size,shape tube and ensure the tube precision.

square tube size:80x80-200x200mm, tube thickness: 4.0-10.0mm

Main Parameters and Specifications:

Material Specifications

Conforming to the YB189-64 standard
Material Low carbon steel and low alloy constructional steel
Mechanical properties σb≤380Mpa,σs≤275MPa
strip width 320～800mm
strip thickness 4.0～10.0mm
I.D of Coils Φ508mm
O.D of Coils φ2000mm
Coil Weight ≤10T

Welded Pipe Specification

square tube size 80x80-200x200mm
pipe thickness 4.0-10.0mm
Finish pipe length 4-8m
Cut length accuracy ±2mm
Forming speed 20-50m/min

workshop require

8m wide, 120m long, at least 6m high from Ceiling Rails to Ground.

ERW Tube Mill Other Model

Model Diameter Range Pipe Thickness Line Speed(m/min)
HG20 8-25.4MM 0.3-1.2MM 120
HG32 10-32MM 1.4-1.5MM 120
HG50 16-76MM 0.7-2.5MM 30-120
HG76 25-76MM 1-4MM 30-100
HG89 32-89MM 1-4.5MM 30-80
HG114 45-114MM 1.5-5.0MM 30-60
HG165 60-165MM 3-7MM 30-50
HG219 114-219MM 4-8MM 20-40
HG273 114-273MM 4-10MM 15-30
HG325 165-325MM 4-10MM 10-30
HG426 165-426MM 4-12.7MM 8-25
HG508 219-508MM 4-16MM 8-20
