Specifications
Brand Name :
PRECISION
Model Number :
VTHC-225
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1
Price :
$6000
Payment Terms :
T/T
Supply Ability :
100/month
Delivery Time :
15 working days
Packaging Details :
Standard export packaging
Customized support :
OEM ODM
Origin :
China
Material :
Stainless Steel
Controller :
Programmable LCD Touch Screen
Temp accuracy: :
0.5°C
Temp uniformity :
0.5°C
Refrigerant :
Environmental friendly
Vibration force :
2000kg.f(20kN)
Temp. range :
-60°C to +180°C
Humdity range :
10% to 98%
Description

AGREE Test Chambers with Vibration Table for Combined Environmental Testing

Product Description:

Our AGREE Test Chambers, equipped with integrated vibration tables, are designed to provide comprehensive environmental and vibration testing capabilities. These chambers meet the rigorous standards of the Advisory Group on Reliability of Electronic Equipment (AGREE), ensuring the reliability and durability of your products under complex combined environmental stresses.

Key Features:

  • AGREE Standard Compliance:
    • Meets or exceeds AGREE standards for combined temperature, humidity, and vibration testing.
    • Ensures accurate simulation of real-world environmental conditions.
  • Integrated Vibration Table:
    • High-performance vibration shakers to simulate various vibration profiles.
    • Adjustable frequency, amplitude, and duration to match specific testing requirements.
  • Precise Temperature and Humidity Control:
    • Advanced control systems for stable and accurate environmental conditions.
    • Wide temperature and humidity ranges to simulate diverse operating environments.
  • Customizable Chamber Sizes:
    • Tailored to accommodate various product sizes and configurations.
    • Ensures efficient testing of diverse product types.
  • Data Acquisition and Analysis:
    • Comprehensive data logging and analysis software for detailed test results.
    • Real-time monitoring of test parameters for immediate feedback.
  • User-Friendly Interface:
    • Intuitive software and control panels for easy operation and test setup.
    • Programmable test sequences for automated testing.
  • Safety Features:
    • Built-in safety mechanisms to protect test specimens and operators.
    • Emergency stop functions for immediate shutdown.
  • Compliance with Industry Standards:
    • Meets or exceeds relevant industry standards, including IEC, ASTM, and MIL-STD.

3. Specific Parameters

  • Shaker Specifications

    Rated Sine/ Random/ Shock Force 1,100 kgf/1,100 kgf/2.200 kgf Armature Mass 11kg
    Frequency Range 5-3.000 Hz Inserts Size (Standard) M8
    Max./Continuous Displacement p-p 51 mm/ 51 mm Load Attachment Points (Standard) 17
    Max. Velocity 2.0 m/s Natural Frequency-Thrust Axis <3Hz
    Max.Sine/ Random Acceleration 100/60g Mac Vertical Load Support 300 kg
    Armature Diameter 235 mm Stray field @ 152 mm above table ≤1mT (10 gauss)
    Fundamental Resonance frequency 2,500 Hz (nom.) ± 5% Dimension LxWxH 940 mmx715 mmx780 mm
    Allowable Armature Overturning Moment 300 Nm Weight (Uncrated) 1.000 kg

    PA10K Power Amplifier Specifications Blower Specifications
    Rated Output Capacity 10kVA Bl ewer Power 4kW
    Signal to Noise Ratio ≥65 dB Air Flow 0.38 m3/s
    Amplifier Efficiency ≥90% Air Pressure 0 048kgf/cm2
    System Protection Multiple Air Duct Diameter/ Length 120/4000mm
    Dimension (Uncrated) LxWxH 610mmx900mmx 1,550mm Dimension (Uncrated) LxWxH 610mmx750mmx 1,450mm
    Weight (Uncrated) 400 kg Weight (Uncrated) 120Kg

    Chamber Dimensions (mm)
    Capacity 512L
    Inner Chamber Dimensions 800×800×800mm (W width × D depth × H height mm)
    Temperature Range -40℃～+150℃
    Cooling Rate

    +20℃～-40℃ Average throughout the range: 2℃/min
    Humidity Range 20%RH～98%RH
    Overall Dimensions

    1200×2500×1500 (W width × D depth × H height mm) excluding lifting table dimensions
    Weight 1500kg

Applications:

  • Reliability testing of electronic components and assemblies.
  • Durability testing of electronic equipment.
  • Environmental stress screening (ESS) of electronic products.
  • Quality assurance for electronic devices.
  • Research and development for new electronic technologies.
  • aerospace and automotive components testing.

AGREE Test Chambers with Vibration Table for Combined Environmental TestingAGREE Test Chambers with Vibration Table for Combined Environmental Testing

Benefits:

  • Ensures compliance with AGREE standards for electronic equipment reliability.
  • Improved product reliability and durability.
  • Reduced warranty costs and product failures.
  • Enhanced product quality and customer satisfaction.
  • Accelerated product development cycles.
  • Combined environmental and vibration testing.
