EA111 BMG 1.4L Naturally Aspirated 75HP Engine Motor Assembly for Skoda Fabia
EA111 BMG 1.4L Naturally Aspirated 75HP Engine Motor Assembly for Skoda Fabia
EA111 BMG 1.4L Naturally Aspirated 75HP Engine Motor Assembly for Skoda Fabia
EA111 BMG 1.4L Naturally Aspirated 75HP Engine Motor Assembly for Skoda Fabia
EA111 BMG 1.4L Naturally Aspirated 75HP Engine Motor Assembly for Skoda Fabia
EA111 BMG 1.4L Naturally Aspirated 75HP Engine Motor Assembly for Skoda Fabia
EA111 BMG 1.4L Naturally Aspirated 75HP Engine Motor Assembly for Skoda Fabia
EA111 BMG 1.4L Naturally Aspirated 75HP Engine Motor Assembly for Skoda Fabia
EA111 BMG 1.4L Naturally Aspirated 75HP Engine Motor Assembly for Skoda Fabia
EA111 BMG 1.4L Naturally Aspirated 75HP Engine Motor Assembly for Skoda Fabia
Specifications
Brand Name :
DHP
Model Number :
CAV
Place of Origin :
China
MOQ :
5
Price :
contact me
Supply Ability :
Steady mass production, short lead time, ready to support large orders.
Packaging Details :
Standard Export Wooden Case
Platform :
EA111, 1.4L Naturally Aspirated (MPI)
Type :
Inline‑4, DOHC 16V, Gasoline, Transverse FWD
Displacement :
1.4L / 1390cc
Bore × Stroke :
76.5 mm × 75.6 mm
volume :
600*450*830
Weight :
82kg
Description

Engine Code: BMG

Family: EA111, 1.4L Naturally Aspirated (MPI)

Type: Inline‑4, DOHC 16V, Gasoline, Transverse FWD

Displacement: 1.4L / 1390cc

Bore * Stroke: 76.5 mm * 75.6 mm

Compression Ratio: 10.5 : 1

Production: 2005–2015

Block / Head: Cast‑iron block / Aluminum head

Timing: Timing chain (maintenance‑free)

Fuel System: MPI Multi‑point Injection

Weight: ~125 kg

Power & Torque
  • Max Power: 55kW / 75HP @ 5000rpm
  • Max Torque: 126N·m @ 3800rpm
Technical Highlights
  • 16V DOHC: Smooth power, good high‑rev response
  • MPI Injection: Simple, reliable, low repair cost
  • Cast‑iron block: Durable, long life, good heat resistance
  • Timing chain: No belt changes, saves maintenance cost
  • Hydraulic lifters: No valve adjustment needed
  • Euro 4 / China IV emission: Fuel‑efficient, daily‑friendly
  • Oil capacity: 3.5L (5W‑40 recommended)
Application (VW / Skoda)
  • VW Polo 9N / 6R 1.4L
  • VW Caddy 1.4L
  • VW Fox 1.4L
  • Skoda Fabia Mk2 1.4L
  • Skoda Roomster 1.4L
Common OE / Assembly Numbers
  • 03C100036D (complete engine)
  • Cylinder head OE: 03C103373E, 03C103351C
Core Selling Points
  1. EA111 BMG 1.4L MPI: 75HP/126N·m, ultra‑reliable NA engine.
  2. Simple MPI design: Less electronics, low failure rate, easy to fix.
  3. Chain timing: Lifetime design, no $500+ belt service.
  4. Cast‑iron block: Tough, high‑mileage friendly, long lifespan.
  5. Excellent fuel economy: ~6L/100km, perfect for city cars.
  6. Wide fitment: Polo/Caddy/Fox/Fabia, strong aftermarket demand.
  7. Tested complete assembly: Ready to install, quality guaranteed.
