3000VA 3000W Off Grid MPPT Solar Inverter Pure Sine Wave 24V - Tianon
3000VA 3000W Off Grid MPPT Solar Inverter Pure Sine Wave 24V - Tianon
Specifications
Certification :
CE
Series :
SY001
Rated Power :
3000VA / 3000W
Low Battery Alarm :
22.0VDC
MPPT Trackers :
1
MOQ :
1 Piece
Payment Terms :
L/C,T/T
Supply Ability :
500 Pieces per Month
Frequency :
50/60Hz (Auto sensing)
Battery Compatibility :
LiFePO4 compatible
Low Battery Cut-off :
21.0VDC
Max PV Current :
80A
Net Weight :
6.7kg
Packaging Details :
Export-grade carton box with shock-proof foam insert and reinforced outer packaging
Transfer Time :
10ms (UPS), 20ms (Appliances)
Parallel Capability :
W/O
Storage Temperature :
-15°C to 60°C
MPPT Operating Range :
50–430VDC
AC Voltage Regulation :
230VAC ±5%
Humidity :
5%–95% RH (Non-condensing)
Operating Temperature :
0°C to 55°C
Low Battery Recovery :
23.0VDC
Max AC Charge Current :
60A
Delivery Time :
35 Calendar Days
Maximum Efficiency :
98%
MPPT :
Solar charge controller inside
Communication :
W/O
Brand Name :
TIANON
Place of Origin :
Xi'an, China
Maximum PV Array Power :
3000W
No Load Consumption :
<35W
Battery Voltage :
24VDC
Gross Weight :
7.2kg
Input Voltage :
230VAC
Float Charge Voltage :
27VDC
Output Waveform :
Pure Sine Wave
Power Factor :
1.0
Model Number :
SY001-C
Display :
LCD
Best Panel Configuration :
600W 2–5 PCS in 1S
Peak Efficiency :
>94%
Max PV Open Circuit Voltage :
450VDC
Surge Power :
6000VA
Overcharge Protection :
32VDC
Packing Size :
473×391×174mm
Price :
Inquiries are welcome
Product Type :
Off Grid MPPT Solar Inverter
Selectable Voltage Range :
90–280VAC (Appliances)
Description
SY001-C 3000VA 3000W Off Grid MPPT Solar Inverter Pure Sine Wave

The TIANON SY001-C is a 3000VA / 3000W off-grid MPPT solar inverter with pure sine wave output. It integrates an MPPT solar charge controller, LCD display, smart battery protection and LiFePO4 battery compatibility, providing reliable power for off-grid residential, home backup and remote-area applications.

Key Features
  • MPPT solar charge controller inside - integrated MPPT for maximum solar harvesting.
  • Wide PV input range - supports flexible solar panel configurations.
  • Pure sine wave output - clean and stable power for sensitive loads.
  • Smart battery protection - protects the battery from overcharge and deep discharge.
  • LiFePO4 compatibility - works with LiFePO4 lithium batteries.
  • Configurable battery & AC/solar priority - adjustable priority via LCD setting.
  • Reliable quality, economic design - cost-effective solution for off-grid power.
Certifications
  • CE - Conformité Européenne marking for European market compliance
Technical Specifications
Product TypeOff Grid MPPT Solar Inverter
SeriesSY001
Input Voltage230VAC
Output WaveformPure Sine Wave
Frequency50/60Hz (Auto sensing)
AC Voltage Regulation230VAC ±5%
Transfer Time10ms (UPS), 20ms (Appliances)
Maximum Efficiency98%
Battery CompatibilityLiFePO4 compatible
DisplayLCD
MPPTSolar charge controller inside
Parallel CapabilityW/O
Humidity5%–95% RH (Non-condensing)
Operating Temperature0°C to 55°C
Storage Temperature-15°C to 60°C
CertificationCE
Rated Power3000VA / 3000W
Selectable Voltage Range90–280VAC (Appliances)
Surge Power6000VA
Power Factor1.0
Peak Efficiency>94%
No Load Consumption<35W
Battery Voltage24VDC
Low Battery Alarm22.0VDC
Low Battery Cut-off21.0VDC
Low Battery Recovery23.0VDC
Float Charge Voltage27VDC
Overcharge Protection32VDC
Maximum PV Array Power3000W
MPPT Operating Range50–430VDC
Max PV Open Circuit Voltage450VDC
MPPT Trackers1
Max PV Current80A
Max AC Charge Current60A
Best Panel Configuration600W 2–5 PCS in 1S
CommunicationW/O
Packing Size473*391*174mm
Net Weight6.7kg
Gross Weight7.2kg
Typical Applications
  • Off-grid residential solar systems
  • Home backup power systems
  • Solar battery energy storage systems
  • Remote-area power applications
  • Solar systems using LiFePO4 batteries
FAQ
  1. What is the rated power? - 3000VA / 3000W (3KVA).
  2. What is the battery voltage? - 24VDC.
  3. Does it output pure sine wave? - Yes, it provides pure sine wave output.
  4. Does it have an MPPT controller? - Yes, an MPPT solar charge controller is integrated.
  5. Is it LiFePO4 compatible? - Yes, it is compatible with LiFePO4 lithium batteries.
  6. Can units be connected in parallel? - No, parallel capability is W/O.
Company Introduction

Shaanxi Tianon New Energy Technology Co., Ltd. is a professional manufacturer of integrated energy storage systems with dual manufacturing hubs in Xi'an (R&D and software) and Anhui (high-volume automated production). With over 10 years of lithium battery export experience, we deliver high-quality ESS products backed by rigorous testing and international certification. We serve distributors and installers in 50+ countries across Europe, North America, and Southeast Asia, with full OEM/ODM support and flexible MOQ from 1 module.

For pricing, samples, or OEM inquiries, contact TIANON ENERGY.
