Insufflator 50L Endoscopy Processor Medical Video Processors Gastroenterology
Insufflator 50L Endoscopy Processor Medical Video Processors Gastroenterology
Insufflator 50L Endoscopy Processor Medical Video Processors Gastroenterology
Insufflator 50L Endoscopy Processor Medical Video Processors Gastroenterology
Insufflator 50L Endoscopy Processor Medical Video Processors Gastroenterology
Insufflator 50L Endoscopy Processor Medical Video Processors Gastroenterology
Specifications
Material :
Plastic and Metal
Product Name :
Endoscopy Processor
Type :
Medical Equipment
MOQ :
1 piece
Price :
Negotiable
Packaging Details :
standard packaging
Delivery Time :
5-7 day
Payment Terms :
T/T etc.
Weight :
Varies
Model Number :
Insufflator 50L
condition :
good
Condition :
New/Used
Description
Insufflator 50L Endoscopy Processor In Good Condition Medical

1. Safely delivers body temperature gas.

2. Single port design.

3. Delivering gas flow at a speed of 50L per minute.

Parameters of Conmed Insufflator 50L

Flow Rate: 50 Liters

Power Supply: 90-240 VAC

Weight: 11.5 lbs

Dimensions: 6.0" (h) x 12.0" (d) x 12.0" (w)

Frequency: 50-60 Hz

The processor has a signal processing circuit that is provided with a digital signal processor. The digital processor generates a coarse video signal that is indirectly displayable on a video screen from image signals generated by a charge coupled device sensor .An auxiliary circuit has a correction circuit that generates another coarse video signal that is directly displayable on the video screen included for the following: (a) video endoscope (b) a camera for an endoscope.

Insufflator 50L Endoscopy Processor Medical Video Processors Gastroenterology

Product Overview

The Conmed 50 L insufflator is a laparoscopic CO2 insufflation unit that establishes and maintains pneumoperitoneum during minimally invasive surgery. It delivers gas flow up to 50 litres per minute through a single-port design, and the warmed gas path helps reduce the cooling and drying effect of cold insufflation on the peritoneal surface. Front-panel control of flow, pressure and gas temperature lets the surgeon keep a stable operative field while the anaesthesia team monitors the physiological response.

Typical Clinical Use
Laparoscopic cholecystectomy, appendectomy and hernia repair where a stable pneumoperitoneum is essential.
Gynaecological laparoscopy and diagnostic procedures requiring controlled abdominal distension.
Long procedures where warmed, humidified gas helps limit peritoneal cooling and post-operative discomfort.
Technical Highlights
Flow rate up to 50 L/min for rapid establishment of pneumoperitoneum and fast compensation of leakage.
Single-port design simplifies tubing and reduces connection points.
Warmed gas delivery to limit moisture loss from the peritoneum.
Wide-range power supply 90-240 VAC, 50-60 Hz, making the unit usable across regions without reconfiguration.
Compact footprint: 6.0 in (H) x 12.0 in (D) x 12.0 in (W), 11.5 lb — practical on a crowded tower or a separate IV pole shelf.
Safe Use and Maintenance

Use only medical-grade CO2 with a clean, dry regulator, and check the over-pressure protection and alarm limits as part of the daily pre-use test. Inline hydrophobic filters must be replaced at the interval defined by the facility protocol, and tubing should be inspected for cracks before every case. Veress needle or trocar placement should always follow the pressure readings displayed by the unit. Remove the water trap and allow the unit to run a self-test before the first case of the day.

Ordering Notes
Is tubing or a filter included?
Consumables are quoted separately so that you receive fresh, in-date stock. Ask for a bundle quotation if you also need filters or tubing.
Condition?
Condition is stated per unit. Units are powered on and checked for flow, pressure regulation and warming function before dispatch.
Delivery and payment?
One piece minimum, dispatch normally within 5-7 working days, T/T accepted, freight quoted to your destination.
Product Specification Summary
ParameterValue
Model NumberInsufflator 50L
MaterialPlastic and Metal
Product NameEndoscopy Processor
WeightVaries
TypeMedical Equipment
conditiongood
