Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Specifications
Model Number :
UT
Place of Origin :
Zhejiang, China
Brand Name :
CAREFUL
Certification :
RoHS
MOQ :
1000 pieces
Price :
$0.50-12.56/pieces
Type :
Wireless Charging Coils
Application :
Industrial Magnet
Brand :
careful
Supplier Type :
factory
Tolerance :
20%
Package Type :
carton
Media Available :
careful catalog
Features :
Industrial Magnet
Function :
Industrial Magnet
Mounting Type :
through hole
Package / Case :
carton
Material - Core :
Amorphous
Sample :
Free Charge
Material :
Many for selection
MOQ :
10 Pcs
Package :
carton
AL :
2-5000
Packaging Details :
Standard exporting carton or as customer's request
Delivery Time :
7-20 Days
Description
Nanocrystalline core soft alloy Advanced technology toroidal Fe-Based Amorphous transformer core
Products Description
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Item
Value
Place of Origin
China
Zhejiang
Brand Name
Careful
Model Number
T
Type
Soft
Composite
Amorphous
Shape
Coil
Application
Industrial Magnet
Tolerance
±10%
Certificates
ISO9001-2015
Permeability
>100000
Material
Amorphous&Nanocrystalline

Specifications Dimensions:mm
A B C D
FC 12×7×4.5-5.7 12±0.4 7±0.3 4.5±0.3 5.7±0.3
FC 12×6×6.5×4.5-4.8 12±0.4 6±0.3 6.5±0.3 4.5±0.3
FC 13.5×6.5×7-4.7 13.5±0.4 6.5±0.3 7±0.3 4.7±0.3
FC 13.5×7.2×7-5.5 13.5±0.4 7.2±0.3 7±0.3 5.5±0.3
FO 15×7.1×6×5.5 15±0.4 7.1±0.3 6±0.3 5.5±0.3
FC 15×7.2×8-5.6 15±0.4 7.2±0.3 8±0.3 5.6±0.3
FO 15×7.2×10-5.5 15±0.4 7.2±0.3 10±0.3 5.5±0.3
FO 15×6.8×10-5.5 15±0.4 6.8±0.3 10±0.3 5.5±0.3
FC 15×7.2×10-6 15±0.4 7.2±0.3 10±0.3 6±0.3
FC 17×7×8-5.5 17±0.4 7±0.3 8±0.3 5.5±0.3
FO 17×7.2×10-5.5 17±0.4 7.2±0.3 10±0.3 5.5±0.3
FC 17×7.2×10-5.5 17±0.4 7.2±0.3 10±0.3 5.5±0.3
FC 17×7.2×5-5.5 17±0.4 7.2±0.3 5±0.3 5.5±0.3

No Specifications Fig Dimensions:mm
A B C D E
1 SCRC 30B 1 11.7±1 10.8±1 4±0.8 21.4±1 2.6±1
2 SCRC 35A 1 13±1 11.8±1 3.5±0.8 25.5±1 2.5±1
3 SCRC 35B 1 13±1 11.8±1 5±0.8 25.5±1 2.5±1
4 SCRC 50 5 16.5±1 / 5±0.8 29.5±1 /
5 SCNF 50 2 15±1 14±1 6±0.8 23.1±1 2.5±1
6 SCRC 50C 1 19.5±1 18±1 5±0.8 35±1 5.5±1
7 SCNF 65 2 17.5±1 19.5±1 6.5±0.8 32.5±1 /
8 SCRC 70A 4 15±1 14±1 7±0.8 18±1 22±1
9 SCRC 70B 1 16.5±1 15±1 7±0.8 30±1 5.5±1
10 SCRC 70C 5 20.7±1 22.2±1 7.2±0.8 39.4±1 /
11 SCRC 80A 3 19.5±1 23±1 8±0.8 17±1 23±1
12 SCRC 80B 3 19.5±1 23±1 8±0.8 19.5±1 26±1
13 SCRC 80C 1 19.5±1 18±1 8±0.8 35±1 5.5±1
14 SCRC 80F 1 19.5±1 18±1 8±1 25.5±1 4.5±1
15 SCRC 90A 4 19.5±1 / 9±0.8 32±1 35.5±1
16 SCRC 90B 1 19.5±1 18±1 9±0.8 35±1 5.5±1
17 SCRC 90C 6 15.6±1 28.3±1 8.5±1 7.5±1 6.45±0.5
18 SCNF 100 2 22±1 23.5±1 10±0.8 33±1 /
19 SCRC 110B 4 20.5±1 33±1 11.0±0.8 32±1 36±1
20 SCNF 130A 2 29±1 30±1 13±0.8 32±1 /
21 SCRC 130B 4 30±1 / 13±0.8 34±1 39±1
22 SCRC 1330B 1 23.5±1 20.5±1 13.5±0.8 36±1 10.5±1
23 SCRC 150A 3 29±1 27±1 13.5±0.8 15.5±1 21.5±1
24 SCRC 20-10-10 3 24±1 31±1 10±0.8 13.5±1 19±1
25 SCRC 24-14-11.4 3 28±1 / 11.4±0.8 17.5±1 23.5±1
26 SCFS 26x9x20.6x17.5-2.6 7 29.1±1 9±0.5 20.6±1.0 21.2±1 2.6±0.5
27 SCFS 33.5X6.8X12-1.8 7 36±1 9.4±0.8 28±1 14.8±1 2±0.4
28 SCFS 35X10X28X15-1.6 7 37.9±1 12.5±0.8 28±1 18±1 2±0.4
29 SCFS 51.5×10×44×15-1.6 7 54±1.5 13.1±0.5 44±1 18.4±1.5 1.6±0.4
30 SCNF 190 2 29±1 29.5±1 19.5±1 42±1 /
31 SCRC 65A 1 17.8±0.4 36.6±0.6 16.8±0.4 8.3±0.3 3±0.3
32 SCRC 65C 8 19±0.4 52.5±0.8 19.5±0.4 7.2±0.3 3.6±0.3
33 SCNF 80D 2 22±1 23.5±1 10±0.8 33±1 19±0.6
34 SCRC 90D 9 19.5±1 32±1 9±1 9±0.5 7.8±0.5
35 SCRC 90F 1 19.7±0.4 17.4±0.4 9±1 39.6±0.6 ■
36 SCRC 90G 1 19.5±1 18±1 9±1 25.5±1 4.5±1
37 SCNF 110 2 25±0.5 32.5±0.6 23±0.5 10±0.4 /
38 SCRC 140A 10 31.6±0.6 40.81±0.7 14.7±0.4 / /
39 SCRC 160A 12 32.2±0.6 33.7±0.2 16.2±0.2 40.05±0.2 /
40 SCRC 185A 13 37.7±2 37.7±0.6 19.2±0.4 / /
41 SCNF 190B 2 29±1 29.5±1 19.5±0.8 42±1 /
42 SCRC 25-12-15 3 29±1 33±1 15±0.8 15.5±1 21.5±1
43 SCRC 24-14-11.4 3 28±1 31±1 11.4±0.8 17.5±1 23.5±1
44 SCRC 200 10 40.2±0.25 46.55±0.25 21.3±0.25 / /
45 SCRC 270A 15 41.8±0.25 45.1±0.25 27.2±0.25 18.4±0.25 /
46 SCRC 230A 15 41±0.2 41±0.2 23±0.25 16.9±0.2 /
47 SCRC 190C 11 30.9±1 36.9±1 20.7±1 / /
48 SCRC 170B 10 42±1 50±1 20±1 / /
49 SCRC 250A 4 40.5±0.2 41±0.2 25±0.2 35.9±0.2 43.3±0.2
50 SCRC 260 14 56±2 42.9±2 24.3±1.5 27.2±1.5 /
Product packaging
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Soft Alloy Nanocrystalline Core Toroidal Fe Based Amorphous Transformer Core
Huzhou Careful Magnetism Co., Ltd. is a technically leading corporation, integrating production, management, research, development and service. Our company was established in 2001, formally known as Huzhou Cifeng Industry Corporation - a key enterprise in Huzhou City. Our company was assessed as "High and New Technology Enterprise in Zhejiang Province". We have more than 20 years of experience in the field, as our boom development, now we own 3 factoies to service more and more clinets.
FAQ
1. Who are we?
We are based in Zhejiang, China, start from 2001,sell to Domestic Market(60.00%),Eastern Europe(10.00%),South Asia(5.00%),Eastern Asia(5.00%),North America(5.00%),Northern Europe(4.00%),South America(3.00%),Southern Europe(3.00%),Western Europe(2.00%),Oceania(1.00%),Central America(1.00%),Southeast Asia(1.00%). There are total about 1000+ people in our office.

2. How can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;

3.What can you buy from us?
Soft Ferrite Core,Amorphous core,Inductors,nizn ferite

4. Why should you buy from us not from other suppliers?
we are the biggest manufacture of ferrite core in China for more than 30 years, also with production line of Amorphous core, SMD core, inductors for years. We are already the supplier of Microsoft,GREE, Midea, SAMSUNG, ASUS, Panasonic, etc.

5. What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery; Accepted Payment Currency: USD, CNY; Accepted Payment Type: T/T, L/C, PayPal, Western Union, Escrow; Language Spoken: English, Chinese
