R·G-8000 Trivalent White Chrome Plating Process Hexavalent Chromium Free Eco Friendly
R·G-8000 Trivalent White Chrome Plating Process Hexavalent Chromium Free Eco Friendly
Specifications
Payment Terms :
T/T
Model Number :
R·G-8000
Product Code :
R·G-8000
Place of Origin :
China
Delivery Time :
5-8 work day
Type :
Trivalent White Chrome Process
pH Value :
2.5-3.0
Operating Temperature :
30-40 ℃
Features :
Hexavalent Cr-Free, Eco-Friendly
Packaging Details :
25kg/drum
Chromium Salt :
140-160 g/L
MOQ :
25-30kg
Description
R·G-8000 Trivalent White Chromium Plating Process
Performance & Features

R·G-8000 trivalent white chromium plating is a new eco-friendly product developed by our company based on imported US technology. Hexavalent-chromium-free coating fully compliant with EU RoHS directives, featuring stable bath performance and high cost performance.

  1. Hexavalent chromium-free eco product with simple wastewater treatment.
  2. Uniform and attractive coating appearance, excellent covering power and leveling power.
  3. No adverse impact if power cuts occur during plating; fast deposition rate.
  4. Imported dedicated graphite anodes improve coating quality and extend bath service life.
Operating Formulation & Parameters
Item Working Concentration / Range
R·G-8000 Composite Salt 250–300 g/L
R·G-8000 Chromium Salt 140–160 g/L
R·G-8000 Stabilizer 55–75 mL/L
R·G-8000 Mist Inhibitor 2–5 mL/L
R·G-8000 Complexing Agent 1–2 mL/L
pH Value 2.5–3.0
Operating Temperature 30–40 ℃
Bath Density 24–26 Bé
Cathode Current Density 8–16 ASD (A/dm²)
Anode Current Density 3.5–5.5 ASD (A/dm²)
Anode Material R·G-8000 special TCP trivalent chromium anodes
Filtration Continuous filtration
Agitation Moderate mechanical agitation or air agitation
Heating Equipment Pure titanium heating tubes
Coating Deposition Rate 0.10–0.125 μm/min
