DS-130 Zinc Plating Trivalent Blue Passivation Process With Wide Operating Window
DS-130 Zinc Plating Trivalent Blue Passivation Process With Wide Operating Window
DS-130 Zinc Plating Trivalent Blue Passivation Process With Wide Operating Window
DS-130 Zinc Plating Trivalent Blue Passivation Process With Wide Operating Window
Specifications
pH Value :
1.8-2.8
Packaging Details :
25kg/drum
Operating Temperature :
15-35 ℃
Place of Origin :
China
Certification :
RoHS, SGS, IATF 16949
Model Number :
DS-130
MOQ :
25-30kg
Product Code :
DS-130
Payment Terms :
T/T
Delivery Time :
5-8 work day
Concentrate :
30-60 mL/L
Immersion Time :
15-50 seconds
Description
DS-130 Trivalent Blue-White Passivation
Performance & Features
  1. New-generation zinc plating passivation agent integrating mature domestic and international technologies.
  2. Low total nitrogen and ammonia nitrogen content, compliant with industrial park wastewater discharge standards.
  3. Wide operating window, producing bright, uniform and elegant blue passivation films.
  4. Neutral Salt Spray (NSS) performance: With coating thickness ≥8 μm and standardized bath maintenance, potassium chloride barrel plating achieves ≥72 hours salt spray resistance; rack plating and alkaline zinc plating deliver even better salt spray performance.
  5. pH adjustment uses sulfuric acid or stock solution instead of nitric acid.
  6. Hexavalent chromium-free passivation film; passed SGS test and IATF 16949 automotive standard, fully compliant with EU RoHS directives.
Operating Parameters
Item Working Range
LC130 Passivation Concentrate 30–60 mL/L
pH Value 1.8–2.8
Operating Temperature 15–35 ℃
Immersion Time (Acid Zinc Plating) 15–50 seconds
Immersion Time (Alkaline Zinc Plating) 15–50 seconds
