Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency
Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency
Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency
Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency
Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency
Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency
Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency
Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency
Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency
Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency
Specifications
Place of Origin :
Guangdong, China
Brand Name :
C-Power
Model Number :
CP-W6012D
Output Type :
Single
Input Voltage :
110v/220v, 220V
Output Voltage :
12V
Output Frequency :
47-63HZ
Output Current :
5A
Application :
LED Lighting
Certification :
CE ROHS
Warranty :
3 Years
Product Name :
waterproof Swtiching Power supply
Type :
Constant Voltage
Protection :
Short Circuit
Efficiency :
86%
Name :
IP67 Led Power
Power :
60w
MOQ :
5 pieces
Price :
$6.70 - $8.00/pieces
Description
Product Description

Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency

Output Voltage: DC 12V,DC 24V

Material: Aluminum

IP Grade: IP67 Waterproof

Working Temperature:-45 to 49degree

Output

DC Voltage

12V

24V

Rated Current

2.5A

1.25A

Current Range

0~2.5A

0~1.25A

Rated Power

30W

30W

Ripple&Noise

120Vp-p

150Vp-p

Set up,Rise time

500ms, 20ms / 230VAC

Input

Voltage Range

170~265VAC 47~62Hz

Efficiency

84%

85%

Ac Current

0.5A/230VAC

Leakage Current

0.25mA / 240VAC

Inrush Current

Cold Start <40A at 230VAC

Protection

Over Current

110~140% rated output power

Protection Type

Hiccup mode, recovers automatically after fault condition is removed

Over Voltage

Hiccup mode, recovers automatically after fault condition is removed

Environment

Working Temp&Humidity

-30-60°C 20-90% RH

Storage Temp&Humidity

-40-80°C 10-90%RH

Safety&EMC

Safety Standards

IP67 Approved ,Design Refer to: EN60950

Withstand Voltage

I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

Isolation Resistance

I/P-O/P:>100M Ohms / 500VDC

EMC Emission

Compliance to EN55022 (CISPR22) Class B,EN61000-3-2 Class A, EN61000-3-3

EMC Immunity

Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, light industry level, Criteria A

Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency

Special Note
This Power Supply Unit "DOES NOT" come with installation instruction, wiring cable,on/off switch, or screws.
Professional Installation of qualified electrician is highly recommended.
Note:
1.This is a DC12V or DC 24V (your choose)Power Supply Unit for professional use on LED lightning, Security Surveillance System, CCTV Security Camera, IP Camera, and etc.
2.Safety design with shortage protection, overload protection and auto voltage switching.
3.Regulated voltage & current output. This is a perfect choice to use as a LED Driver for all type of LED lighting 3.without flickering light & ensue the life span of your LED.
4.Full range of current output is possible for LED lighting with dimmable function.
About Calculate Method:
If Your LED Strip 60LEDs/m, and each LED 0.2W, then calculate max led Strip Length: 0.2W/LED × 60LEDs/m=12W/m, 24W(this listing)÷12W/m=2m,
So, Support the LED Strip(60LEDs/m, 0.2W/LED) Length (Max)=2m
Special Note:
This Power Supply Unit "DOES NOT" come with installation instruction, on/off switch, or screws.
Professional Installation of qualified electrician is highly recommended.

Packaging & Shipping

Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency

Our Services

Single Output 60W 5A IP67 Waterproof LED Power Supply 12V AC/DC with 86% Efficiency

1,Promotely reponse and fast production leadtime 2,Best pre-sale & after-sale service

3,Reliable products quality and good reputation 4,High manufacturing capacity
