LED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A Regulated
LED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A Regulated
LED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A Regulated
LED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A Regulated
LED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A Regulated
LED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A Regulated
Specifications
Place of Origin :
Guangdong, China
Brand Name :
C-Power
Model Number :
CP-600512S
Output Type :
Single
Input Voltage :
110v/220v, 110V
Output Voltage :
5V
Output Frequency :
50/60Hz
Output Current :
12A
Application :
LED Lighting
Certification :
CE
Warranty :
3 Years
Product Name :
power supply 5v 12a
Type :
Constant Voltage
Efficiency :
82%
Color :
Silver
Name :
5v dc power supply
Brand :
C-Power
MOQ :
10 pieces
Price :
$4.50/pieces 10-2999 pieces
Description
Product Description

Model

CP-600512S

DC output voltage

5V

Output voltage tolerance

±2%

Rated output current

12A

Output current range

0-12A

Ripple and noise

50mVp-p

Inlet stability

±0.5%

Load stability

±1%

DC output power

60W

Efficiency

82%

Output voltage adjustment range

±10%

AC input voltage range

85~132VAC/170~265VAC/47~63VAC,120~370VDC

Input current

0.6A/115V 0.35A/230V

AC impulse current

Cold-start current 15A/115V 30A/230V

Leakage current

<0.75mA/240VAC

Overload protection

105%~150% Type,PULSING HICCUP SHUTDOWN,Reset,auto recovery

Over-voltage protection

115%~135% rated output power

Temperature coefficient

±0.03%°C(0~50°C)

Setup rise hold up time

800ms,50ms,20ms/115VAC 300ms,50ms,80ms/230VAC

Vibration

10~500Hz,2G 10min./1cycle,Period for 60min,Each axes

Withstand voltage

I/P-O/P:2.5KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

Isolation resistance

I/P-O/P I/P-FG O/P-FG:500VDC/100MΩ

Working temperature and humidity

-10°C~+60°C,20~90%RH

Store temperature and humidity

-20°C~+85°C,10~95%RH

Safety standards

Desgin refer to UL1012,EN60950-1,EN61347-1,EN-61347-2 approved

EMC standards

EN55015,EN55022,EN55024,EN61000-2,EN61000-3,EN61547 approved

LED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A RegulatedLED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A RegulatedLED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A RegulatedLED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A Regulated

Packaging & Shipping

LED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A Regulated

Our Services

LED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A Regulated

1,Promotely reponse and fast production leadtime 2,Best pre-sale & after-sale service

3,Reliable products quality and good reputation 4,High manufacturing capacity

5.OEM/ODM

Company Information

LED Lighting Constant Voltage Switch Power Supply 12V 5A 5V 1A 2A 3A 5A 12A Regulated
