480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
Specifications
Place of Origin :
China
Brand Name :
C-Power
Model Number :
CP-24-20
Output Type :
Single
Input Voltage :
110v 220v
Output Voltage :
24V
Output Frequency :
50/60Hz
Output Current :
20A
Application :
Led Strip
Certification :
CE FCC ROHS
Warranty :
3 Years
Efficiency :
90%
Product Name :
LED Swtiching Power Supply
Type :
Constant Voltage
Protections :
Short Circuit Overtemp Overload Overvolt
Service :
Customised OEM ODM
Price :
$17.50 - $19.50/pieces
Packaging Details :
1. Individual box in white box .
2. Strong and solid carton for overseas shipping;
3. Packages can be OEM or ODM.
4. Delivery time: 1-2 days for stock, about 1 week if no stock.
5. Can ship by air or by sea or send to buyers' shipper/pa
Supply Ability :
1000000 Piece/Pieces per Month
MOQ :
5 pieces
Description
Product Description

480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications

High Quality uninterrupted 24V 20A 480W dc power supply

1. Protections: Short circuit / Overload / Over voltage / Over temperature

2. 100% full load burn-in test

3. best cost, high reliability

DC output voltage
24V
Rated output
20A
Output current rage
0-10A
Wave and noise
240mVp-p
Inlet stability
±0.5%
Load stablity
±1%
Efficiency
90%
Adjustable range for voltage
±10%
AC input voltage range
AC100~240V 47~63Hz;240~370VDC
Input current
2A/115V 1A/230V
AC INnrush current
Cold-start current 18A/115V 36A/230V
Overload proctection
Tpye:Foldback current limiting Reset: auto recovery
Over-voltage protection
Hiccup mode, auto-recovery
Setup rise hold up time
200s,100ms,20ms
Withstand voltage
Input and output internal 1.5KVAC,Input and enclosure 1.5KVAC,Output and enclosure 0.5KVAC
Isolation resistance
Input and output internal Input and enclosure,Output and enclosure 500VDC/100MΩ
Working temperature
-10°C~+50°C

480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications

Our Services

480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications

1,How many voltage can you supply?

-- 5V, 6.5V,9V 10V,12V, 13.5V, 15V, 18V, 19V, 24V 36V, 48V (depend on items)

2,How many current can you supply?

-- 0.5A, 1A,1.25A, 1.5A, 2A, 2.5A,3A, 3.42A,4A, 5A, 6A, 10A, 15A 20A, 30A, 40A, 50A, 60A

3,How about the quality?

-- We have the best professional and experienced engineer and strict QA and QC system. Repair rate under 1.1%-0.2%

480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications

Packaging & Shipping

We offer the palletized delivery to our honourable customer by sea.

The palletized delivery detail as following:

480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications

FAQ

480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications

How's your power supply and adapter quality?

-- 100% burn-in test, full-round tests. All products are CE approved, We promise less than 1% defetive within one year (history defetive rate is around 0.2% defetive in a year).If within 1% defetive, just show us inner unique serial number of defetive products and we can replace for free in the next order; if defective rate is higher than 5% because of product quality problem, will promise you to replace for free .

480W 24V 20A Single Output Switching Power Supply for High Power Industrial Applications
