180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included
180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included
180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included
180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included
180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included
180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included
Specifications
Place of Origin :
Guangdong, China
Brand Name :
C-Power
Model Number :
CP-18012A
Output Type :
Single
Input Voltage :
110v/220v, 220V
Output Voltage :
12V
Output Frequency :
50/60Hz
Output Current :
15a
Application :
LED Lighting
Certification :
CE
Warranty :
3 Years
Type :
Constant Voltage
Protection :
Over-voltage
Efficiency :
82%
Input voltage :
220v ac
Current :
15a
Power :
180W
MOQ :
5 pieces
Price :
$4.80/pieces 5-499 pieces
Description
Product Description

OEM ODM 12v switching power supply 180w 15A class 2 power supply

Feature

1.Universal AC input / full range
2.Input Frequency 47-63Hz
3.low products cost, high quality level
4.100% aging test
5.AC input Voltage range: 110/220VAC±20%, Selected by switch
6. Short circuit / Overload Protection
7. Soft-start current , reduce the AC input Inrush
8. Installed with EMI filter, minimun wave
9. Small size, light weight, long life , high efficiency

Model

CP-180-12

Output

DC output voltage

12V

Output voltage tolerance

±1%

Rated output current

15A

Output current

0~15A

Output power

180W

Ripple and noise

80mVp-p

DC adjustable range

±10%

Setup rise hold up time

50ms

Input

Input voltage range

85~132VAC 170~264VAC 47~63Hz, 240~370VDC

AC input current

6.5A/115V 4A/230V

Efficiency

82%

AC inrush current

Cold start current 25A/115V 50A/230V

Leakage current

<3.5mA/240VAC

Protection characteristic

Over load protection

105%~135%rated output power start the over load protection

Protection mode : cut off the output,auto-recovery

Over-voltage protection

115%-135% cut off the output,auto-recovery

Over-temp protection

Rectifier≥80°Ccut off the output ,auto-recovery

Fan ON/OFF control

≥55°C Fan start ,≤45°CFan off

Environment

Working temperature

-10°C~+60°C;20%~90%RH(please refer to the Load deduction curve)

Security

Withstand voltage

Between input and output:1.5KVACThe input and ground : 1.5KVACThe output and ground :0.5KVAC

Insulation resistance

Between input and output:The input and ground, the output and ground: 100M 0hms /500VDC
180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included
Our Services

180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included

1,How many voltage can you supply?

-- 5V, 6.5V,9V 10V,12V, 13.5V, 15V, 18V, 19V, 24V 36V, 48V (depend on items)

2,How many current can you supply?

-- 0.5A, 1A,1.25A, 1.5A, 2A, 2.5A,3A, 3.42A,4A, 5A, 6A, 10A, 15A 20A, 30A, 40A, 50A, 60A

3,How about the quality?

-- We have the best professional and experienced engineer and strict QA and QC system. Repair rate under 1.1%-0.2%

4,What’s your MOQ?

-- 3000pcs, except for sample order or trial order.

Packaging & Shipping

  • 180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included

FAQ

180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included

How's your power supply and adapter quality?

-- 100% burn-in test, full-round tests. All products are CE approved, We promise less than 1% defetive within one year (history defetive rate is around 0.2% defetive in a year).If within 1% defetive, just show us inner unique serial number of defetive products and we can replace for free in the next order; if defective rate is higher than 5% because of product quality problem, will promise you to replace for free .

180w 15A Class 2 Power Supply for OEM ODM 12v Switching Over-voltage Protection Included
