DBET-52/350G24K4V Proportional valve German Rexroth original overflow valve
DBET-52/350G24K4V Proportional valve German Rexroth original overflow valve
DBET-52/350G24K4V Proportional valve German Rexroth original overflow valve
DBET-52/350G24K4V Proportional valve German Rexroth original overflow valve
Specifications
Brand Name :
Rexroth
Model Number :
DBET-52/350G24K4V
Certifiion :
ISO
Place of Origin :
German
MOQ :
1
Payment Terms :
Western Union,T/T,D/P,D/A,L/C
Supply Ability :
100
Delivery Time :
2 weeks
Packaging Details :
wooden box
Specifiion :
cast iron
Material :
High-grade steel and aluminum
Pump :
Rexroth
Pressure Rating :
280 bar
Warranty :
one year
Power :
Hydraulic
Seal Type :
Lip Seal or Mechanical Seal
Description
DBET-52/350G24K4V Proportional Valve

German Rexroth original overflow valve for industrial hydraulic systems.

Technical Specifiions
Parameter Item Specifiion / Description
Product Series / Type DBET (Proportional Pressure Relief Valve, Direct-Operated)
Nominal Size 52 (Port size or nominal size specifiion)
Rated Pressure 350 bar
Operating Voltage 24 V DC
Electrical Connection K4 (Type of electrical connector)
Control Signal / Option V (Voltage input signal, 0-10V)
Maximum Operating Pressure 350 bar
Maximum Flow Rate 2-3 L/min (Typical for size 6 valves)
Hydraulic Fluid Compatibility Mineral-based hydraulic oils (HL, HLP, HVLP types)
Fluid Cleanliness Requirement ISO 4406 Class 18/16/13 or better
Operating Temperature Range -20°C to +80°C (Fluid temperature)
Ambient Temperature Range -20°C to +50°C
Mounting Interface ISO 4401 standard (Subplate mounting)
DBET-52/350G24K4V Proportional valve German Rexroth original overflow valve
Related Product Models
DBET-52/350G24K4V
DBET-52/350G24K4M
DBET-52/315G24K4V
DBET-52/315G24K4M
DBET-52/200G24K4V
DBET-52/200G24K4M
DBET-52/100G24K4V
DBET-52/100G24K4M
DBETE-52/350G24K31F1V
DBETE-5X/50G24K31A1M
DBETE-5X/100G24K31A1V
DBETE-5X/350G24K31F1M
DBETE-5X/350G24K31A1V
DBETE-5X/350G24K31A1M
DBETE-5X/315G24K31F1V
DBETE-5X/315G24K31A1V
DBETE-5X/315G24K31A1M
DBETE-5X/200G24K31F1V
DBETE-5X/200G24K31F1M
DBETE-5X/200G24K31A1V
DBETE-5X/200G24K31A1M
DBETE-5X/100G24K31F1V
DBETE-5X/100G24K31F1M
DBETE-5X/100G24K31A1M
DBET-5X/350G24K4V
DBETE-5X/50G24K31F1V
DBETE-5X/50G24K31F1M
DBET-5X/350G24K4M
DBET-5X/315G24K4V
DBET-5X/315G24K4M
DBET-5X/200G24K4V
DBET-5X/200G24K4M
DBET-5X/100G24K4V
DBET-5X/100G24K4M
DBET-5X/50G24K4V
DBET-5X/50G24K4M
DBETE-5X/50G24K31A1V
DBETE-5X/315G24K31F1M
DBETE-5X/350G24K31F1V
DBETBEX-1X/310G24K31A1M
DBETFX-1X/80G24-27NZ4M
DBETFX-1X/180G24-27NZ4M
DBETFX-1X/250G24-27NZ4M
DBETFX-1X/315G24-27NZ4M
DBETX-10/50G24-8NZ4M
DBETX-10/80G24-8NZ4M
DBETX-10/180G24-8NZ4M
DBETX-10/50G24-25NZ4M
DBETX-10/80G24-25NZ4M
DBETX-10/180G24-25NZ4M
DBETX-10/250G24-25NZ4M
DBETX-10/315G24-25Z4M
DBET6X/50G24K4V
DBET6X/100G24K4V
DBETB-6X/315G24K31A1V
DBETB-6X/350G24K31A1V
DBE6X-1X/80G24-8NZ4M
DBE6X-1X/180G24-8NZ4M
DBE6X-1X/80G24-25NZ4M
DBE6X-1X/180G24-25NZ4M
DBE6X-1X/315G24-25NZ4M
DBEBE6X-1X/80G24K31F1M
DBE10Z-1X/180XYG24-8NZ4M
DBE10Z-1X/315XYG24-8NZ4M
DBEB10Z-1X/180XYG24-37Z4M
DBEB10Z-1X/315XYG24-37Z4M
DBEBE10Z-1X/180XYG24K31A1M
DBEBE10Z-1X/315XYG24K31A1M
DBEME20DBEME30
DBEME10-5X/50YG24K31M
Frequently Asked Questions
What is the operating voltage and current requirement?
The DBET-52/350G24K4V operates on 24V DC (G24) power supply. The typical current consumption is 0.8A to 1.0A. Ensure the power supply is stable and within ±10% tolerance for reliable operation.
What is the maximum working pressure?
This model has a maximum working pressure of 350 bar (as indied by "/350" in the model number). Do not exceed this pressure limit to prevent valve damage or system failure.
What type of control signal does it accept?
The "K4V" in the model number indies it accepts a 0-10V voltage input signal for proportional pressure control. Ensure the control signal is clean, properly shielded, and free from electrical noise.
What hydraulic fluid is compatible?
The valve is compatible with standard hydraulic oils including HL, HLP, HVLP types. Maintain fluid cleanliness to ISO 18/16/13 or better. Operating temperature range is typically -20°C to +80°C.
How to troubleshoot if the valve doesn't respond?
First verify:
  • 24V DC power supply is present and stable
  • Control signal (0-10V) is within range and properly connected
  • Hydraulic fluid is clean and at proper level
  • Check electrical connections for corrosion or loose wires
  • If issues persist, the valve may require service or replacement
