PVV21-1X/045-036RA15UUMB PVV2-1X/068RJ15UMB PVV42-1X/122-068RA15UUMC Rexroth PVV series high-performance variable vane pump, available in stock for PVV21, PVV42, PVV2 and other models made in Italy
PVV21-1X/045-036RA15UUMB PVV2-1X/068RJ15UMB PVV42-1X/122-068RA15UUMC Rexroth PVV series high-performance variable vane pump, available in stock for PVV21, PVV42, PVV2 and other models made in Italy
PVV21-1X/045-036RA15UUMB PVV2-1X/068RJ15UMB PVV42-1X/122-068RA15UUMC Rexroth PVV series high-performance variable vane pump, available in stock for PVV21, PVV42, PVV2 and other models made in Italy
PVV21-1X/045-036RA15UUMB PVV2-1X/068RJ15UMB PVV42-1X/122-068RA15UUMC Rexroth PVV series high-performance variable vane pump, available in stock for PVV21, PVV42, PVV2 and other models made in Italy
Specifications
Brand Name :
Rexroth
Model Number :
PVV21-1X/045-036RA15UUMB PVV2-1X/068RJ15UMB PVV42-1X/122-068RA15UUMC
Certifiion :
ISO
Place of Origin :
Italy
MOQ :
1
Payment Terms :
Western Union,T/T,D/P,D/A,L/C
Supply Ability :
100
Delivery Time :
2 weeks
Packaging Details :
wooden box
Pumptype :
Variable Displacement / Fixed Displacement
Warranty :
one year
Rotation :
0.2-cp can be transported in reverse
Mounting Type :
Flange, Foot, and Face
Maximum Pressure :
280 bar
Efficiency :
Up to 95%
Nominal Pressure :
315 / 400 /350
Speed :
Hydraulic oil, water ethylene glycol
Description
Rexroth PVV Series Fixed Displacement Vane Pumps
The Rexroth PVV series comprises high-performance fixed-displacement vane pumps designed for industrial and mobile hydraulic appliions. These pumps are engineered for reliability, efficiency, and ease of maintenance, making them suitable for demanding environments such as machine tools, plastic machinery, and marine equipment.
Featured Models
Model Type Displacement Frame Size Max Pressure Speed Range
PVV21-1X/045-036RA15UUMB Double Pump 45.4 cm³ (Flange)
36.4 cm³ (Cover)		 21 210 bar 600-2800 rpm
PVV2-1X/068RJ15UMB Single Pump 67.5 cm³ 2 210 bar 600-2800 rpm
PVV42-1X/122-068RA15UUMB Double Pump 121.6 cm³ (Flange)
67.5 cm³ (Cover)		 42 210 bar 600-2800 rpm
Key Features & Benefits
  • Long Bearing Life: Hydraulically unloaded shaft design reduces wear and extends service life
  • Low Operating Noise: Optimized vane movement ensures quiet operation
  • Easy Maintenance: Replaceable pump cartridges allow quick servicing without disassembling the entire housing
  • High Efficiency: Advanced hydraulic balancing minimizes energy loss
  • Flexible Configuration: Optional pressure connection positions and rotation directions
  • Compact Design: Ideal for space-constrained appliions
Appliions
  • Industrial Machinery: Machine tools, plastic injection molding, and die-casting equipment
  • Mobile Hydraulics: Marine steering systems, construction machinery, and agricultural equipment
  • Custom Solutions: Double pumps provide separate oil outputs for complex systems
Frequently Asked Questions
General Product Questions
What is the warranty period for Rexroth PVV pumps?
Standard warranty terms apply (typically 1-2 years). Consult with authorized distributors for specific terms.
Are these pumps compatible with fluids other than mineral oil?
Yes, they support phosphate ester (HFD-R) fluids when equipped with FKM seals (indied by "V" in the model code).
Can I replace the pump cartridge myself?
Yes. The modular design allows users to remove the cover and replace the cartridge without disassembling the entire pump housing.
Technical Specifiions
What does the model code "PVV21-1X/045-036RA15UUMB" mean?
  • PVV: Industrial fixed-displacement vane pump
  • 21: Double pump with frame size 21
  • 045-036: Displacements (flange side: 45.4 cm³, cover side: 36.4 cm³)
  • R: Clockwise rotation
  • A: Cylindrical shaft
  • UUM: Pressure connections at bottom on both flange and cover sides
  • B: Seal material (NBR)
What is the maximum flow rate of the PVV2-1X/068RJ15UMB at 1500 rpm?
Approximately 100 L/min at 1500 rpm, based on displacement and speed.
Ordering & Support
How do I order these pumps?
Contact authorized distributors (e.g., Wuhan Bifoyou Mechanical & Electrical Equipment Co.) for pricing and delivery terms.
Where can I find technical drawings or CAD files?
Visit the official Rexroth website or refer to product documentation for downloadable resources.
What is the lead time for delivery?
Standard orders typically ship within 3 days of payment confirmation.
Ordering Information
To order or request a quote, provide the complete model number, quantity, and delivery address. For technical support, share your appliion parameters (e.g., pressure, speed, and fluid type) with authorized distributors.
Specifiions are subject to change. Refer to the latest Rexroth documentation for accurate details.
