DBETE-52/200G24K31A1V Rexroth proportional pressure relief valve made in Germany
DBETE-52/200G24K31A1V Rexroth proportional pressure relief valve made in Germany
DBETE-52/200G24K31A1V Rexroth proportional pressure relief valve made in Germany
DBETE-52/200G24K31A1V Rexroth proportional pressure relief valve made in Germany
Specifications
Brand Name :
Rexroth
Model Number :
DBETE-52/200G24K31A1V
Certifiion :
ISO
Place of Origin :
Germany
MOQ :
1
Payment Terms :
Western Union,T/T,D/P,D/A,L/C
Supply Ability :
100
Delivery Time :
2 weeks
Packaging Details :
wooden box
Efficiency :
Up to 95%
Origin :
Germany
Charging :
micro5p
Productname :
Rexroth Hydraulic Pump
Maximum Pressure :
315 bar
Shaft Diameter :
25mm
Fluid Compatibility :
Mineral Oil or Synthetic Fluids
Description
DBETE-52/200G24K31A1V Rexroth Proportional Pressure Relief Valve
Professional-grade proportional pressure relief valve manufactured in Germany for precision hydraulic control appliions.
Technical Specifiions
Parameter Value / Description
Product Model DBETE-52/200G24K31A1V
Nominal Pressure Rating 200 bar (maximum operating pressure at port P)
Supply Voltage 24 V DC (±10%, 21 to 35 V DC permissible range)
Electrical Connection 6-pin plug + PE, compliant with DIN 43563 standard
Control Signal Input 0 to 10 V analog signal (A1 type)
Protection Class IP65 (dust-tight and protected against water jets)
Ambient Temperature Range -20 °C to +50 °C (operating temperature)
Hydraulic Fluid Compatibility Mineral-based hydraulic oils (HL, HLP per DIN 51524), viscosity range: 10-800 mm²/s
Seal Material FKM (fluorocarbon rubber, indied by 'V' suffix)
Product Image
DBETE-52/200G24K31A1V Rexroth proportional pressure relief valve made in Germany
Related Product Models
DBET-5X/350G24K4V
DBETE-5X/50G24K31F1V
DBETE-5X/50G24K31F1M
DBET-5X/350G24K4M
DBET-5X/315G24K4V
DBET-5X/315G24K4M
DBET-5X/200G24K4V
DBET-5X/200G24K4M
DBET-5X/100G24K4V
DBET-5X/100G24K4M
DBET-5X/50G24K4V
DBET-5X/50G24K4M
DBETE-5X/50G24K31A1V
DBETE-5X/315G24K31F1M
DBETE-5X/350G24K31F1V
DBETBEX-1X/310G24K31A1M
DBETFX-1X/80G24-27NZ4M
DBETFX-1X/180G24-27NZ4M
DBETFX-1X/250G24-27NZ4M
DBETFX-1X/315G24-27NZ4M
DBETX-10/50G24-8NZ4M
DBETX-10/80G24-8NZ4M
DBETX-10/180G24-8NZ4M
DBETX-10/50G24-25NZ4M
DBETX-10/80G24-25NZ4M
DBETX-10/180G24-25NZ4M
DBETX-10/250G24-25NZ4M
DBETX-10/315G24-25Z4M
DBET6X/50G24K4V
DBET6X/100G24K4V
DBETB-6X/315G24K31A1V
DBETB-6X/350G24K31A1V
DBE6X-1X/80G24-8NZ4M
DBE6X-1X/180G24-8NZ4M
DBE6X-1X/80G24-25NZ4M
DBE6X-1X/180G24-25NZ4M
DBE6X-1X/315G24-25NZ4M
DBEBE6X-1X/80G24K31F1M
DBE10Z-1X/180XYG24-8NZ4M
DBE10Z-1X/315XYG24-8NZ4M
DBEB10Z-1X/180XYG24-37Z4M
DBEB10Z-1X/315XYG24-37Z4M
DBEBE10Z-1X/180XYG24K31A1M
DBEBE10Z-1X/315XYG24K31A1M
DBEME20DBEME30
DBEME10-5X/50YG24K31M
DBEME10-5X/100YG24K31M
DBEME10-5X/200YG24K31M
DBEME10-5X/315YG24K31M
DBEME10-5X/350YG24K31M
DBEME20-5X/50YG24K31M
DBEME20-5Xyi00YG24K31M
DBEME20-5X/200YG24K31M
DBEME20-5X/315YG24K31M
DBEME20-5X/350YG24K31M
DBEME30-3X/50YG24K31M
DBEME30-3X/100YG24K31M
DBEME30-3X/200YG24K31M
DBEME30-3X/315YG24K31M
DBEME30-3X/350YG24K31M
DBEE6-1X/50YG24K31M
DBEE6-1X/100YG24K31M
DBEE6-1X/200YG24K31M
DBEE6-1X/315YG24K31M
ZDBEE6VP2-1X/50G24K31M
ZDBEE6VP2-1X/100G24K31M
Frequently Asked Questions
What is the nominal pressure rating and maximum flow rate?
The nominal pressure rating is 200 bar, and the maximum flow rate is 2 L/min at this pressure. For optimal performance and longevity, it's recommended to operate within these specified limits.
What are the electrical specifiions and control signal requirements?
The valve operates on a 24 V DC power supply (permissible range: 21-35 V DC). The control input accepts an analog 0 to 10 V signal (A1 type). Electrical connection is via a 6-pin plug with PE, compliant with DIN 43563 standard.
What is the protection class and operating temperature range?
The valve has an IP65 protection class, making it dust-tight and protected against water jets. The ambient temperature range for operation is -20 °C to +50°C.
What hydraulic fluids and seal materials are compatible with this valve?
This model is compatible with mineral-based hydraulic oils (HL, HLP per DIN 51524 standards), with a viscosity range of 10-800 mm²/s. The seal material is FKM (fluorocarbon rubber), indied by the 'V' suffix in the model number.
What is the typical response time and hysteresis performance?
The typical response time for a full signal change is less than 70 ms. The hysteresis is typically ≤ 1%, ensuring precise pressure control with minimal deviation between increasing and decreasing pressure cycles.
