R900597233 DR20-5-5X/200YM Stacked pressure reducing valve Rexroth German hydraulic valve
R900597233 DR20-5-5X/200YM Stacked pressure reducing valve Rexroth German hydraulic valve
Specifications
Packaging Details :
wooden box
Supply Ability :
100
Place of Origin :
German
Model Number :
DR20-5-5X/200YM
Max. Operating Pressure (P, A, B)​ :
315 bar
Order Code​ :
R900597233
Max. Reduced Pressure​ :
200 bar
Payment Terms :
Western Union,T/T,D/P,D/A,L/C
Delivery Time :
2 weeks
Fluid Temp. Range​ :
-20°C to +80°C
Brand Name :
Rexroth
Certifiion :
ISO
MOQ :
1
Parameter :
Specifiion
Description

Parameter

Specifiion

Order Code​

R900597233

Type​

Stacked Proportional Pressure Reducing Valve

Manufacturer​

Rexroth

Max. Reduced Pressure​

200 bar

Nominal Size / Flow​

NG 20 / ~250 l/min

Max. Operating Pressure (P, A, B)​

315 bar

Control Type​

Proportional Solenoid (OBE)

Control Signal​

PWM (24V DC typical)

Mounting​

Sandwich plate, NG20 (ISO 7368)

Fluid Temp. Range​

-20°C to +80°C

Viscosity Range​

10 to 400 mm²/s

Country of Origin​

Made in Germany

R900597233 DR20-5-5X/200YM Stacked pressure reducing valve Rexroth German hydraulic valve

DR6DP1-5X/210YV
DR6DP1-5X/210Y
DR10-5-4X/200YV
DR10DP2-4X/150Y
DR10DP2-4X/150YM
DR20-4-5X/200YM
DR20-5-5X/50YM
DR10DP2-4X/75Y
DR10DP2-4X/75YM
DR10DP2-4X/25YM
DR30-4-5X/315YM
DR10-4-5X/315YM
DR10DP1-4X/75YM
DR10DP2-4X/210YM
DR30-5-5X/50YM
DR30-5-5X/50Y
DR10-5-5X/200Y
DR10-5-5X/50Y
DR20-4-5X/200Y
DR30-5-5X/350YM
DR30-4-5X/200Y
DR20-5-5X/200YV
DR30-6-5X/50YM
DR25G5-5X/200YM
DR30-5-5X/200YV
DR30-4-5X/200YM
DR30-5-5X/200YMV
DR10-7-5X/100Y
DR20-5-5X/50YV
DR10G4-5X/50YM
DR20-5-5X/315YMV
DR20-4-5X/50Y

Frequently Asked Questions (FAQ) for Rexroth DR 20-5-5X/200YM (R900597233)

Q1: What is the core function of this valve?

A:​ It is a three-port proportional pressure reducing valve. It electronically reduces a high primary system pressure (up to 315 bar) to a lower, stable, and adjustable secondary pressure (up to 200 bar) for a specific branch of a hydraulic circuit.

Q2: What does the "5-5X" in the model number indie?

A:​ This suffix specifies the internal control spool design and damping characteristics. The "5-5X" variant is a common standard configuration optimized for general-purpose appliions with balanced dynamic response and stability.

Q3: How does it differ from the DR 20G5-4X/100YM model?

A:​ The two key differences are:

  1. Maximum Reduced Pressure:​ This model (200YM) provides up to 200 bar, double the 100 bar of the G5-4X/100YM variant.

  2. Spool Design:​ The "5-5X" spool has different dynamic performance characteristics (flow capacity, response) compared to the "G5-4X" spool.

Q4: What is the flow capacity?

A:​ As an NG20 size valve, it has a nominal flow rate of approximately 250 liters per minute. The actual usable flow depends on the specific pressure drop; refer to the official performance curves.

Q5: How is the valve controlled?

A:​ It is controlled by a standard 24V DC PWM signal. The integrated onboard electronics (OBE) on the proportional solenoid simplify wiring, requiring only a PWM source from a PLC or amplifier.

Q6: How is it installed in a hydraulic system?

A:​ It is a sandwich valve. It mounts directly between a NG20 subplate​ (e.g., Rexroth RE 20-5 series) and another valve or cover plate above it, building a modular manifold stack.
