R900500255 DR20-4-5X/200YM Rexroth stacked pressure reducing valve made in Germany
R900500255 DR20-4-5X/200YM Rexroth stacked pressure reducing valve made in Germany
Specifications
Brand Name :
Rexroth
Model Number :
DR20-4-5X/200YM
Certification :
ISO
Place of Origin :
Germany
MOQ :
1
Payment Terms :
Western Union,T/T,D/P,D/A,L/C
Supply Ability :
100
Delivery Time :
2 weeks
Packaging Details :
wooden box
Max. Reduced Pressure​ :
200 bar
Max. Operating Pressure (P, A, B, T)​ :
315 bar
Control Signal​ :
PWM (typically 24V DC)
Manufacturing Origin​ :
Made in Germany
Mounting​ :
Sandwich plate, ISO 7368 (NG20) interface
Description

Parameter

Specification

Function​

Stacked, Proportional Pressure Reducing Valve

Max. Reduced Pressure​

200 bar

Nominal Size/Flow​

NG 20 / ~250 l/min

Max. Operating Pressure (P, A, B, T)​

315 bar

Control Type​

Proportional Solenoid (with onboard electronics)

Control Signal​

PWM (typically 24V DC)

Mounting​

Sandwich plate, ISO 7368 (NG20) interface

Manufacturing Origin​

Made in Germany

R900500255 DR20-4-5X/200YM Rexroth stacked pressure reducing valve made in Germany

DR20-5-5X/315YM
DR10-4-5X/315Y
DR10-5-5X/100Y
DR30-5-5X/315YM
DR20-4-5X/100YM
DR10-4-5X/200YM
DR10-5-5X/315Y
DR30-4-5X/315Y
DR20-5-5X/315Y
DR30-5-5X/100YMV
DR10-5-5X/315YM
DR30-5-5X/200YM
DR10-5-5X/100YM
DR20-5-5X/100Y
DR20-5-5X/200YM
DR30-5-5X/100YM
DR20-5-5X/100YM
DR20-5-5X/100YV
DR30-5-5X/315YV
DR20-4-5X/315YM
DR20G5-5X/200YM
DR10-4-5X/100Y
DR20-5-5X/200Y
DR10-5-5X/200YM
DR10-5-5X/50YM
DR20-5-5X/50Y
DR10-5-5X/100YV
DR30-4-5X/100Y
DR10-5-5X/200YMV
DREE20-5X/200YG24K31M
DR3U10E5-5X/100Y6EG24N9K4V
DR30-7-5X/350YM
DRE10-5X/100YG24K4M
DREM10-5X/100YG24K4M
DREM10-5X/200YG24K4M
DREM10-5X/200YMG24K4M
DREME10-5X/100YG24K31M
DRE6-1X/210MG24K4M
DRE6-1X/100MG24K4M
DREE10-5X/315YMG24K31M
DREM10-5X/100YMG24K4M

Frequently Asked Questions (FAQ) for Rexroth DR 20-4-5X/200YM (R900500255)

Q1: What is the main function of this valve?

A:​ It is a proportional pressure reducing valve​ for larger hydraulic systems. It electronically controls and maintains a precise, stable pressure (up to 200 bar) in a subsystem, regardless of the primary circuit's pressure.

Q2: What is the key difference between the "200YM" and a "315YM"?

A:​ The "200" specifies the maximum adjustable reduced pressure​ is 200 bar. The "315YM" model can be set up to 315 bar. Otherwise, the "YM" (proportional control) function is identical.

Q3: What does the "NG 20" size mean?

A:​ "NG 20" is the Nominal Size 20. It indicates a larger valve with larger flow passages, designed for flows up to approximately 250 liters per minute​ (significantly higher than an NG10 valve at ~80 l/min).

Q4: How is it installed?

A:​ It is a sandwich valve. It mounts between a NG20 subplate​ (e.g., Rexroth RE 20 series) and another valve or cover plate, forming a modular manifold block for high-flow circuits.

Q5: How is the pressure controlled?

A:​ It is controlled by a standard PWM signal​ (typically 24V DC) via its integrated proportional solenoid with onboard electronics (OBE), requiring a compatible amplifier or controller card.
