R900244765 4WRZ25W6-325-7X/6EG24N9ETK4/D3M Rexroth Germany hydraulic servo proportional valve
R900244765 4WRZ25W6-325-7X/6EG24N9ETK4/D3M Rexroth Germany hydraulic servo proportional valve
Specifications
Certifiion :
ISO
Order Number​ :
R900244765
MOQ :
1
Brand Name :
Rexroth
Model​ :
4WRZ25W6-325-7X/6EG24N9ETK4/D3M
Control Signal​ :
±10 V DC​ or 4–20 mA​ (requires external amplifier)
Rated Flow​ :
325 L/min​ (at Δp = 10 bar per control land)
Place of Origin :
Germany
Delivery Time :
2 weeks
Packaging Details :
wooden box
Max. Operating Pressure​ :
P, A, B: 350 bar; T port: 210 bar​
Payment Terms :
Western Union,T/T,D/P,D/A,L/C
Model Number :
R900244765 4WRZ25W6-325-7X/6EG24N9ETK4/D3M
Supply Ability :
100
Description

Parameter

Specifiion

Order Number​

R900244765​

Model​

4WRZ25W6-325-7X/6EG24N9ETK4/D3M

Type​

Pilot-operated, 2-stage proportional directional valve

Function​

4/3-way (3 positions, 4 ports), spring-centered

Spool Type​

W6 (Overlap spool, O-type mid-position)​

Nominal Size​

NG25​ (CETOP 8)

Max. Operating Pressure​

P, A, B: 350 bar; T port: 210 bar​

Rated Flow​

325 L/min​ (at Δp = 10 bar per control land)

Max. Flow​

Approx. 870 L/min​

Electronics​

External Electronics (EE)​

Supply Voltage​

24V DC​ (19.4...35 VDC)

Control Signal​

±10 V DC​ or 4–20 mA​ (requires external amplifier)

Feedback​

Yes (LVDT, closed-loop spool position)​

Pilot Oil Supply​

Internal (from P)​

Pilot Oil Return​

Internal (to T)​

Manual Override​

Yes (N9, concealed)​

Pressure Reducing Valve​

Yes (D3, ZDR 6 DP0-4X/...)​

Seal Material​

NBR (M)​

Electrical Connector​

3-pin (2 + PE) plug (DIN EN 175301-803, K4)

Mounting Interface​

ISO 4401-08-08-0-05 (CETOP 8 subplate)

Suitable Media​

Mineral oils (HL, HLP), HETG, HEES, HEPG, HFDU, HFDR

Media Temperature​

-20°C to +80°C​ (optimal 40–50°C)

Viscosity Range​

20 to 380 mm²/s

Weight​

Approx. 18.7 kg​ (with D3 option)

R900244765 4WRZ25W6-325-7X/6EG24N9ETK4/D3M Rexroth Germany hydraulic servo proportional valve

4WRZE25W6-325-72/6EG24N9EK31/F1D3M
4WRZE25W6-325-72/6EG24N9EK31/F1M
4WRZE25W6-325-72/6EG24N9ETK31/A1D3M
4WRZE25W6-325-72/6EG24N9ETK31/A1M
4WRZE25W6-325-72/6EG24N9ETK31/F1D3M
4WRZE25W6-325-72/6EG24N9K31/A1M
4WRZE25W6-325-72/6EG24N9K31/A1V
4WRZE25W6-325-72/6EG24N9K31/F1D3M
4WRZE25W6-325-72/6EG24N9K31/F1D3V
4WRZE25W6-325-72/6EG24N9K31/F1M
4WRZE25W6-325-72/6EG24N9K31/F1V
4WRZE25W6-325-72/6EG24N9TK31/A1D3M
4WRZE25W6-325-72/6EG24N9TK31/F1D3V
4WRZE25W8-220-72/6EG24EK31/A1D3M
4WRZE25W8-220-72/6EG24EK31/F1D3M
4WRZE25W8-220-72/6EG24ETK31/A1D3M
4WRZE25W8-220-72/6EG24K31/A1D3M
4WRZE25W8-220-72/6EG24K31/F1D3M
4WRZE25W8-220-72/6EG24N9EK31/A1D3M
4WRZE25W8-220-72/6EG24N9EK31/F1D3M
4WRZE25W8-220-72/6EG24N9ETK31/F1D3M
4WRZE25W8-220-72/6EG24N9ETK31/F1D3V
4WRZE25W8-220-72/6EG24N9K31/A1D3V
4WRZE25W8-220-72/6EG24N9K31/A1M
4WRZE25W8-220-72/6EG24N9K31/F1D3M
4WRZE25W8-325-72/6EG24EK31/A1D3M
4WRZE25W8-325-72/6EG24EK31/F1D3M
4WRZE25W8-325-72/6EG24ETK31/A1D3M
4WRZE25W8-325-72/6EG24ETK31/F1M
4WRZE25W8-325-72/6EG24K31/A1D3M
4WRZE25W8-325-72/6EG24K31/A1M
4WRZE25W8-325-72/6EG24N9EK31/A1D3M
4WRZE25W8-325-72/6EG24N9EK31/A1D3V
4WRZE25W8-325-72/6EG24N9EK31/A1V
4WRZE25W8-325-72/6EG24N9EK31/F1D3M
4WRZE25W8-325-72/6EG24N9EK31/F1D3V
4WRZE25W8-325-72/6EG24N9ETK31/F1D3M
4WRZE25W8-325-72/6EG24N9ETK31/F1D3V
4WRZE25W8-325-72/6EG24N9K31/A1D3M
4WRZE25W8-325-72/6EG24N9K31/A1M
4WRZE25W8-325-72/6EG24N9K31/F1D3M
4WRZE25W9-220-72/6EG24N9EK31/A1D3M
4WRZE25W9-220-72/6EG24N9EK31/A1D3V
4WRZE25W9-220-72/6EG24N9ETK31/A1D3V
4WRZE25W9-220-72/6EG24N9K31/A1D3M
4WRZE25W9-220-72/6EG24N9K31/F1D3M
4WRZE25W9-325-72/6EG24N9EK31/A1D3M
4WRZE25W9-325-72/6EG24N9K31/A1D3M
4WRZE32E1-360-72/6EG24ETK31/A1D3M
4WRZE32E1-520-72/6EG24ETK31/A1D3M
4WRZE32E1-520-72/6EG24N9K31/A1D3M
4WRZE32E360-72/6EG24ETK31/A1D3M
4WRZE32E360-72/6EG24K31/A1M
4WRZE32E520-72/6EG24EK31/A1D3M
4WRZE32E520-72/6EG24EK31/F1D3M
4WRZE32E520-72/6EG24ETK31/A1D3M
4WRZE32E520-72/6EG24K31/A1D3M
4WRZE32E520-72/6EG24N9ETK31/A1M
4WRZE32E520-72/6EG24N9K31/A1D3V
4WRZE32E520-72/6EG24N9TK31/A1D3M

FAQ:

  1. Q: What is the main difference between this valve and the previous R900958570?

    A:​ This valve (R900244765) uses internal pilot oil return (to T, "ET" code), which eliminates the need for an external Y-port drain line. The previous model required an external Y-port connection. This simplifies plumbing but requires that the T-port backpressure remains below 30 bar​ to ensure proper pilot valve function.

  2. Q: What does the /D3M suffix mean?

    A:​ The /D3​ suffix indies an integrated pressure reducing valve (ZDR 6)​ for regulating pilot pressure. The /M​ suffix specifies standard NBR seals.

  3. Q: How does the pilot oil configuration work?

    A:​ This valve (/6EG24N9ETK4) uses internal pilot oil supply (from main P port) and internal pilot oil return (to main T port). This "ET" configuration is the most convenient as it requires no external pilot lines, but you must ensure the main tank line (T-port) backpressure is controlled.

  4. Q: Why choose this specific configuration?

    A:​ This model is ideal for high-flow appliions (325 L/min) requiring simplified plumbing. The internal pilot drain (ET)​ reduces the number of hydraulic connections, while the integrated /D3 pressure reducer​ protects the pilot stage from system pressure fluctuations.

  5. Q: What is the critical installation note?

    A:​ Since the pilot stage drains internally to T, you must ensure the main T-port backpressure is below 30 bar. High backpressure on T can prevent the pilot valve from draining properly, causing erratic main stage operation. Maintain high oil cleanliness (recommended NAS 1638 Class 8 or better for the main stage).
