4WRZ16E100-7X/6EG24N9TK4/D3M 4WRZ16E100-7X/6EG24N9TK4/M 4WRZ16E100-7X/6EG24N9ETK4/D3M Proportional Rexroth electro-hydraulic directional valve, German made original hydraulic valve
4WRZ16E100-7X/6EG24N9TK4/D3M 4WRZ16E100-7X/6EG24N9TK4/M 4WRZ16E100-7X/6EG24N9ETK4/D3M Proportional Rexroth electro-hydraulic directional valve, German made original hydraulic valve
4WRZ16E100-7X/6EG24N9TK4/D3M 4WRZ16E100-7X/6EG24N9TK4/M 4WRZ16E100-7X/6EG24N9ETK4/D3M Proportional Rexroth electro-hydraulic directional valve, German made original hydraulic valve
4WRZ16E100-7X/6EG24N9TK4/D3M 4WRZ16E100-7X/6EG24N9TK4/M 4WRZ16E100-7X/6EG24N9ETK4/D3M Proportional Rexroth electro-hydraulic directional valve, German made original hydraulic valve
Specifications
Brand Name :
Rexroth
Model Number :
4WRZ16E100-7X/6EG24N9TK4/D3M 4WRZ16E100-7X/6EG24N9TK4/M 4WRZ16E100-7X/6EG24N9ETK4/D3M
Certifiion :
ISO
Place of Origin :
German
MOQ :
1
Price :
2
Payment Terms :
MoneyGram,Western Union,T/T,D/A,D/P,L/C
Supply Ability :
100
Delivery Time :
2 weeks
Packaging Details :
wooden box
Drive Mode :
Mechanically Driven Pump
Theory :
Rotary Pump
Flowrate :
Up to 200 L/min
Origin :
China
Speed :
3 Speed Settings
Shafttype :
Splined / Keyed
Pressurerating :
Up to 350 bar
Condition :
Internal meshing principle
Delivery Date :
5 days
Mnr :
R902463126
Description
4WRZ16E100-7X/6EG24N9TK4/D3M Proportional Rexroth Electro-Hydraulic Directional Valve
German-made original hydraulic valve designed for precision control in industrial hydraulic systems.
Product Specifiions
Selection Dimension Specific Parameters/Options Description
Model Designation 4WRE Basic model: Direct-acting proportional directional valve with electrical position feedback and no integrated electronics (OBE)
Integrated Electronics (OBE) No Code Standard configuration without integrated electronics; external amplifier required (to be ordered separately)
Nominal Size 6 Core size with component series 2X; mounting dimensions comply with Series 20-29 standards
Valve Core Type 4/2 (2-position 4-way), 4/3 (3-position 4-way) 4/3 type features spring-centered spool for automatic reset when de-energized; suitable for different oil circuit directional control needs
Rated Flow (Δp=10bar) 4L/min (Code 04), 8L/min (Code 08), 16L/min (Code 16), 32L/min (Code 32) Flow rates distinguished by corresponding codes; matched to hydraulic system flow requirements
Seal Material V (FKM Fluororubber) Default FKM material; compatible with mineral oil and other hydraulic fluids to ensure sealing performance
Power Supply Voltage G24 (DC 24V) Suitable for industrial standard DC power supply; meets proportional solenoid drive requirements
Electrical Interface A1 (±10V Voltage Input), F1 (4-20mA Current Input) Two interface options available; compatible with PLCs, computers, and other control signal sources
Electrical Connection K4 (No Plug) Plug compliant with DIN EN 175301-803 standard required (to be ordered separately)
Special Protection J (Seawater-Resistant) Only available for Size 6; suitable for marine-related or humid/corrosive working conditions
Mounting Standard ISO 4401 Panel mounting with standard mounting hole pattern; compatible with universal hydraulic system manifold layouts
Maximum Working Pressure 315bar Suitable for most medium-to-high pressure industrial hydraulic scenarios (e.g., hydraulic actuators in machine tools, automated production lines)
4WRZ16E100-7X/6EG24N9TK4/D3M 4WRZ16E100-7X/6EG24N9TK4/M 4WRZ16E100-7X/6EG24N9ETK4/D3M Proportional Rexroth electro-hydraulic directional valve, German made original hydraulic valve
Related Model Variants
4WRZ32W9-360-70/6EG24N9TK4/D3M
4WRZ32W9-360-70/6EG24N9ETK4/M
4WRZ32W9-360-70/6EG24N9K4/M
4WRZ32W8-520-70/6EG24N9TK4/D3M
4WRZ32W8-520-70/6EG24N9ETK4/M
4WRZ32W8-520-70/6EG24N9K4/M
4WRZ32W8-360-70/6EG24N9TK4/D3M
4WRZ32W8-360-70/6EG24N9ETK4/M
4WRZ32W8-360-70/6EG24N9K4/M
4WRZ32W6-520-70/6EG24N9TK4/M
4WRZ32W6-520-70/6EG24N9ETK4/D3M
4WRZ32W6-520-70/6EG24N9ETK4/M
4WRZ32W6-520-70/6EG24N9EK4/D3M
4WRZ32W6-520-70/6EG24N9EK4/M
4WRZ32W6A360-70/6EG24N9K4/M
4WRZ32E1-520-70/6EG24N9TK4/M
... and additional model configurations available
Frequently Asked Questions
  • What is the ambient temperature range for 4WRZ operation?
    Operating ambient temperature: -20 °C to +70 °C; storage temperature: -20 °C to +80 °C.
  • What hydraulic fluids are compatible with 4WRZ valves?
    Approved fluids include HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFdu, and HFdr.
  • What seal materials are used in 4WRZ valves?
    Standard seals are FKM (Viton); NBR seal kits are also available as spare parts.
  • What is the weight of a size 25 4WRZ valve for subplate mounting?
    Approximately 18.2 kg (18.7 kg with "D3" option).
  • What is the pilot oil supply range for external supply?
    External pilot oil supply pressure ranges from 20-100 bar (sizes 32-52) to 30-100 bar (sizes 10-16).
