R900423720 DBDS6G1X/315 Rexroth Germany overflow valve
R900423720 DBDS6G1X/315 Rexroth Germany overflow valve
Specifications
Place of Origin :
Germany
Delivery Time :
2 weeks
Model :
DBDS 6 G1X / 315
Packaging Details :
wooden box
Max. Adjustable Relief Pressure :
315 bar (31.5 MPa)
Payment Terms :
Western Union,T/T,D/P,D/A,L/C
Supply Ability :
100
Certification :
ISO
Valve Type :
Direct-acting seat-type pressure relief valve (DBD series)
Part Number :
R900423720
Brand Name :
Rexroth
MOQ :
1
Nominal Size (NG) :
6
Model Number :
R900423720 DBDS6G1X/315
Description
R900423720 DBDS6G1X/315 Rexroth Germany Overflow Valve
Product Overview

Direct-acting seat-type pressure relief valve from the DBD series, designed for reliable pressure control in hydraulic systems.

Technical Specifications
ParameterValue
Part NumberR900423720
ModelDBDS 6 G1X / 315
Valve TypeDirect-acting seat-type pressure relief valve (DBD series)
Nominal Size (NG)6
Connection TypeScrew-in cartridge / threaded for manifold block (G = threaded connection, pipe thread G 1/4" ISO 228-1 on the cavity)
Adjustment TypeHexagon socket setscrew with protective cap (P1 equivalent, adjustable by Allen key), component series 1X
Max. Adjustable Relief Pressure315 bar (31.5 MPa)
Max. Operating Pressure (P-port)630 bar
Max. Flow Rate (Qmax)approx. 50 L/min (for Size 6 DBD)
Number of Ports2 (P → T)
Seal MaterialNBR (standard)
Hydraulic FluidMineral oil HL, HLP per DIN 51524; HFC (water-glycol); HLPD, HVLP, HVLPD
Fluid Temperature Range-30 °C to +80 °C (NBR seals)
Viscosity Range10 - 800 mm²/s
Weight (approx.)1.56 kg
Body MaterialSteel, zinc-plated
R900423720 DBDS6G1X/315 Rexroth Germany overflow valve
Related Products
R900438939 DBDS6K1X/400V
R900769564 DBDS6K1X/190E
R900769414 DBDS10K1X/160E
R900424149 DBDS10K1X/200
R900424183 DBDH10K1X/315
R900424152 DBDS10K1X/400
R900424269 DBDS20K1X/200
R900424286 DBDS30K1X/200
0811109135 ZDBY6DA2-1X/80V/60
R900409844 ZDB6VP2-4X/200V
R900409898 ZDB6VP2-4X/315V
R900426329 ZDB6VA2-4X/200
R900411314 Z2DB6VD2-4X/200V
R900409955 ZDB10VA2-4X/315V
R900409958 ZDB10VP2-4X/315V
R900411358 Z2DB10VD2-4X/200V
R900505052 DB10-1-5X/200
R900598998 DB10-1-5X/315
R900590334 DB10-2-5X/315
R900502117 DB20-1-5X/200
R900587346 DB20-1-5X/315
R983037993 DBDH10G1X/315
R900425660 DBDS10P1X/400
R900424277 DBDS20P1X/200
R900424279 DBDS20P1X/400
R900923103 DBW10B1-5X/200-6EG24N9K4
R900912910 DBW10B2-5X/200-6EG24N9K4
R900920863 DBW10B1-5X/315-6EG24N9K4
R900906285 DBW10B2-5X/315-6EG24N9K4
R901216280 DAW30B2-5X/200-FS6EG24N9K4
R900479509 DR6DP1-5X/25YM
R900450964 DR6DP2-5X/75YM
R901418087 Z3DR6VP3-1X/315V
R900431172 ZDR6DB2-4X/150YM
R900483785 ZDR6DP2-4X/25YM
R900483786 ZDR6DP2-4X/75YM
R900483787 ZDR6DP2-4X/150YM
R900410884 ZDR10DA2-5X/150Y
R900410875 ZDR10DP2-5X/75YM
R900410880 ZDR10DP2-5X/150YM
R900410876 ZDR10DP2-5X/210YM
R900408340 ZDR10DB2-5X/150YM
R900962883 DR10-4-5X/100YM
R900598358 DR10-5-5X/200YM
R900597132 DR10-5-5X/315YM
R900500255 DR20-4-5X/200YM
R900417545 DR20G5-4X/100YM
R900597283 DR20-5-5X/100YM
R900597233 DR20-5-5X/200YM
R900596339 DR30-5-5X/100Y
R900597158 DR30-5-5X/200YM
R900596814 DR30-5-5X/315YM
R900323180 ZDR6DPO-4X/40YMW80
R900481621 Z2FS6-2-4X/1Q
R900564522 Z2SFK10-2-1X/2QV
R900517812 Z2FS10-5-3X/V
R900459203 Z2FS16-8-3X/S
Frequently Asked Questions
Q1: Is DBDS6G1X/315 pilot-operated or direct-acting?
It is a direct-acting seat valve (DBD series). The ball/poppet opens immediately when system pressure overcomes the spring preload — no pilot stage is involved.
Q2: What does "G1X / 315" mean in the model?
  • G = designed for threaded/screw-in cartridge installation into a manifold block with G 1/4" threaded cavity
  • 1X = component series index (dimensionally interchangeable within series 1X)
  • /315 = spring pressure stage — maximum adjustable relief pressure is 315 bar
Q3: How do I install this valve?
The valve screws into a prepared manifold block cavity with G 1/4" ISO 228-1 threaded port. Ensure the P-port in the block aligns with system pressure and T-port connects to tank. Use appropriate sealing (O-ring on the cartridge shoulder or thread sealant on the threaded portion as per the cavity drawing). Torque typically approx. 45-50 N·m — refer to the official Rexroth mounting drawing for your specific cavity.
Q4: How do I adjust the relief pressure?
With the system depressurized, remove the protective cap, turn the internal setscrew with an Allen key — clockwise to increase, counterclockwise to decrease. Reinstall the cap after setting and verify with a pressure gauge at the P-port. Factory preset is typically near the low end of the spring range; always re-set on-site.
Q5: Does T-port backpressure affect the set pressure?
Yes. Backpressure at the tank side adds 1:1 to the cracking/relief pressure because the spring chamber drains internally to T. Keep T-line backpressure minimal or subtract it from your desired setpoint during adjustment.
Q6: What if the valve does not reach set pressure or chatters?
  • Low/no pressure: Wrong spring grade, high T-backpressure, or severely contaminated oil causing poppet sticking
  • Chatter / noise: Air in the system, excessive flow beyond Qmax for Size 6, or remote piping resonance — bleed air from the system and confirm flow ≤50 L/min
  • Leakage in closed position: Damaged seating surface or contaminated oil trapped in the seat — clean or replace the cartridge
Q7: Can it be used with biodegradable or water-based fluid?
Standard NBR seals are approved for HFC (water-glycol). For HEES/HETG biodegradable oils or HFD (phosphate ester), FKM (Viton) seals are required — order the "V" seal variant if needed and verify fluid compatibility.
