CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton
CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton
CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton
CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton
CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton
CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton
CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton
CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton
Specifications
Brand Name :
JCYC
Model Number :
SY
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Price :
586usd
Payment Terms :
L/C,T/T
Supply Ability :
500 pcs / month
Delivery Time :
15 working days
Packaging Details :
Pallet
Product :
Electric Chain Hoist
Usage :
Construction Hoist
Condition :
New
Lift speed :
6.8 m/min
Warranty :
1 Year
Power source :
Electric
Sling type :
Chain
Maximum lifting height :
100m
Maximum lifting weight :
25t
Lifting height :
3~12m or customized
Description
Hook Suspension Type Electric Chain Hoist

The SY Electric Chain Hoist is manufactured using advanced Japanese technology and features a dual braking system to ensure maximum safety and reliable operation. It is designed with a high-strength aluminum alloy housing, offering a compact structure and lightweight design. The double-gear transmission system delivers smooth, stable operation with low noise. All critical components are made from high-strength alloy steel with special heat treatment, effectively preventing sudden failure and extending service life.

Main Features

  • Dual braking system for enhanced operational safety

  • Available in single-speed and dual-speed versions

  • Limit switch for safe and reliable lifting control

  • Electromagnetic brake for fast and stable stopping

  • Heavy-duty waterproof control pendant, suitable for outdoor and harsh environments

  • Hook suspension design for easy installation and flexible movement

Technical Specifications
Model Capacity (t) Lifting speed (m/min) Lifting motor power(kw) Rotation speed (r/min) Phases Voltage (v) Frequency(Hz/s) I-beam (mm)
SY0.5-01 0.5 7.8 1.1 1440 3 220-440 50/60 68-130
SY01-01 1 6.8 1.5 1440 3 220-440 50/60 68-130
SY01-02 1 3.9 1.1 1440 3 220-440 50/60 68-130
SY02-01 2 6.6 3.0 1440 3 220-440 50/60 82-153
SY02-02 2 3.4 1.5 1440 3 220-440 50/60 82-153
SY03-01 3 5.6 3.0 1440 3 220-440 50/60 82-153
SY03-02 3 4.4 3.0 1440 3 220-440 50/60 82-153
SY05-02 5 2.8 3.0 1440 3 220-440 50/60 100-178
CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton

CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton

CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton

CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton

CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton

CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton

Manufacturing Excellence
CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton
Industry Presence
CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton
CE Certified Hook Suspension Type Electric Chain Hoist Lifting Capacity 3 Ton
