Specifications
Brand Name :
JCYC
Model Number :
ER
Certification :
ISO CE
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500 pcs / week
Delivery Time :
3 working days
Packaging Details :
Plywood case
Product :
ER Electric Chain Hoist
Lifting Speed :
Dual Speed 3.5/7 m/min
Voltage :
220 v - 440 v
Color :
Orange
Motor Power :
1.5-3.6 KW
Work Duty :
M5, M4
Description
M5 Work Level Electric Chain Hoist With Dual Lifting Speed
Product Overview

Engineered for reliable operation in demanding industrial environments and intensive working conditions, this electric chain hoist meets M5 duty classification requirements with dual lifting speed capabilities.

Key Features
High Duty Rating - M5 Grade

Engineered for reliable operation in demanding industrial environments and intensive working conditions, meeting M5 duty classification requirements.

Robust & Fully Sealed Housing
  • Lightweight yet highly durable construction
  • Excellent heat dissipation performance
  • Fully enclosed design suitable for dusty, humid, and harsh industrial environments
Phase Reversal Protection

Equipped with a phase protection device that prevents operation when the power supply phases are connected incorrectly, ensuring safe and reliable performance.

Upper & Lower Limit Switches

Built-in limit switches automatically stop lifting and lowering movements at the end positions, helping prevent over-travel and equipment damage.

24V/36V Low-Voltage Control

Low-voltage control system enhances operational safety and reduces risks associated with electrical leakage from the pendant control.

Reliable Brake System

The electromagnetic brake engages immediately when power is interrupted, ensuring secure load holding and safe operation.

Durable Chain Bag

Lightweight, attractive, and highly wear-resistant, providing safe and organized storage for the load chain during operation.

High-Strength FEC80 Alloy Steel Chain

Manufactured from imported FEC80 alloy steel and subjected to precision heat treatment, delivering excellent strength, wear resistance, and long service life under heavy-duty working conditions.

Technical Specifications
Model Capacity (T) Unit (mm) Speed 50HZ (m/min) Motor (kw) Minimum radius of turn I-Beam
SY-ET-0.5 0.5 198 12.2 0.12 0.8 52-153
SY-ET-01 1 315 11-21 0.4 0.8 52-153
SY-ET-02 2 325 11-21 0.4 0.8 82-178
SY-ET-03 3 340 11-21 0.4 1 100-178
SY-ET-05 5 400 11-21 0.75 1.8 100-178
SY-ET-7.5 7.5 400 11-21 0.75 1.8 100-178
SY-ET-10 10 500 11-21 0.75 2.5 150-220
Product Images
M5 Work Duty ER Electric Chain Hoist with Dual Lifting Speed and FEC80 Alloy Steel Chain M5 Work Duty ER Electric Chain Hoist with Dual Lifting Speed and FEC80 Alloy Steel Chain M5 Work Duty ER Electric Chain Hoist with Dual Lifting Speed and FEC80 Alloy Steel Chain
Factory Overview
M5 Work Duty ER Electric Chain Hoist with Dual Lifting Speed and FEC80 Alloy Steel Chain
