Specifications
Brand Name :
JCYC
Model Number :
SY-A
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
$300-$10000
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
500 pcs / week
Delivery Time :
20 working days
Packaging Details :
Plywood case
Model :
Standard Headroom Type
Capacity :
20 ton
Voltage :
220 V - 440 V
Color :
As per request
Chain Dia. :
11.2 mm
Work Load :
0.25-5 ton
Hoist Power :
3 kw
Rail Width :
100-200 mm
Height :
3m-50m
Lifting Power :
8/0.8kw
Hoist Height :
3-50 M
Key Words :
Electric Chain Hoist, Electric Trolley
Protection Grade :
IP54
Chain Length :
standard 3m
Lowering Speed :
3m/min
Description
Standard Headroom Electric Chain Hoist With Electric Trolley 20 ton
Brief Introduction

Electric chain hoist has a small,compact,light weight and cool design,use single/triple phase power supply,quickly and easily operates,easy to install,security,reliability and widely using. Ideal lifting tools for DIY, warehouses, garages, farms, hunting, engine repair shops, machine shops, restaurants, AD boards hold, show and home improvement etc, also perfect for loading and unloading heavy items from trucks and trailers.

Main advantages
Structure Features

The body chooses to use high strength tensile shell or die casting aluminum case, extrusion molding process thin-walled precision manufacturing, small size, low weight, high strength. Seperate speed-adjusting system, seal the level 2 coaxial transmission speed gear mechanism with long-service oil bath lubrication system. The electric hoist powder metallurgy clutch is used for overload protection device. The brake disc adopts dc magnetic field, braking torque, stable and rapid, the noise is small.

Lifting motor

Using high performance lifting motor which can last to work 30 minutes with full loading, and has Grade B insulation.

Lifting chain

The chain of the low carbon steel alloy makes the chain more toughness, strong and wear-resisting, ensuring the safety during work.
Lifting chain hardened surface can prevent the damage of the core materials and products to soften, thus make lifting chain keep for a long time high performance.The chain can be also extended according to the request of customers' order, and allows you to use more conveniently.
The chain is equipped with chain bag which makes the electric hoist looks clean, tidy and beautiful. the chain bag contains antirust oil, so the chain is not easy to rust , so as to extend the service life of the electric hoist.

Double brake system

Two sets of brake systems, not only reduce the brake failure possibility, but also increase its safety and benefit for heat radiation. Variable speed toothThe standard chain electric hoist mainly use the reliable helical gear, it can prolong service lifting through reducing the meshing impact and vibration. Special design of gear enhance the durability of gear, And gear is made of alloy steel, through professional fine heat treatment obtain the biggest strength.

Control handle with low voltage

The standard low-voltage on chain hoist handle is 24v-36v. Low voltage can effectively protect the operator to prevent a shock damage.(24V-36V is compulsive National standard.

20 ton Capacity 220V-440V Voltage Electric Chain Hoist with 3m-50m Height and Motorized Trolley 20 ton Capacity 220V-440V Voltage Electric Chain Hoist with 3m-50m Height and Motorized Trolley
Lifting Capacity(t) Lifting Height(m) Lifting Speed(m/min) Running Speed(m/min) Lifting Motor Running Motor I-Beam(mm)
Power(kw) R.P.M(r/min) Power Supply Power(kw) R.P.M(r/min) Power Supply
0.5 3-9 6.8 12.2 0.75 1440 220-440V 50/60HZ 3Phase 0.12 1440 220-440V 50/60HZ 3Phase 58-130
1 3-9 6.6 10/20 1.5 1440 0.4 1440 80-160
1 3-9 3.4 10/20 0.75 1440 0.4 1440 80-160
2 3-9 6.6 10/20 3.0 1440 0.4 1440 82-178
2 3-9 3.3 10/20 1.5 1440 0.4 1440 82-178
3 3-9 5.4 10/20 3.0 1440 0.4 1440 100-180
3 3-9 4.4 11/21 3.0 1440 0.4 1440 100-178
3 3-9 2.4 11/21 1.5 1440 0.4 1440 110-178
5 3-9 2.7 10/20 3.0 1440 0.75 1440 110-180
7.5 3-9 1.8 10/20 3*2 1440 0.75 1440 120-180
10 3-9 2.7 10/20 3*2 1440 0.75 1440 150-202
15 3-9 1.9 10/20 3*2 1440 0.75*2 1440 150-220
20 3-9 1.4 10/20 3*2 1440 0.75*2 1440 150-220
25 3-9 1.1 10/20 3*2 1440 0.75*2 1440 150-220
30 3-9 0.9 10/20 3*2 1440 0.75*2 1440 150-220
35 3-9 0.7 10/20 3*2 1440 0.75*2 1440 150-220
