Low Headroom Electric Chain Hoist With Traveling Trolley Safe Operation
Low Headroom Electric Chain Hoist With Traveling Trolley Safe Operation
Low Headroom Electric Chain Hoist With Traveling Trolley Safe Operation
Low Headroom Electric Chain Hoist With Traveling Trolley Safe Operation
Low Headroom Electric Chain Hoist With Traveling Trolley Safe Operation
Low Headroom Electric Chain Hoist With Traveling Trolley Safe Operation
Specifications
Brand Name :
JCYC
Model Number :
HSY-L
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
5800 pcs per month
Delivery Time :
About 5 working days
Packaging Details :
Plywood case
Product name :
Low Headroom Electric Chain Hoist
Lifting height :
standard 3m or custom
Capcity :
0.5T-7.5T
Feature :
Low Headroom
Application :
construction
Color :
Yellow or Customized Color
Voltage :
220v-440v
Description
Low Headroom Electric Chain Hoist with Traveling Trolley
Product Description:

The Low Headroom Electric Chain Hoist is designed for optimal space-saving and efficient lifting in tight environments. Featuring a self-traveling trolley, it moves effortlessly along I-beams while maintaining a low profile. This hoist combines durable materials like pure copper motors and manganese steel chains for superior performance and safety. It also includes advanced features like a dual brake system, limit switches, and customizable options.

Key Features:

  • Compact & Space-Saving Design: Ideal for low-clearance spaces, offering efficient performance without occupying too much headroom.

  • Self-Traveling Trolley: Can move easily along I-beams, offering great flexibility and saving installation space.

  • Durable Materials: Features a high-performance pure copper motor and G80 manganese steel chain, ensuring a longer lifespan and stronger tensile strength.

  • Safety Features: Includes a dual brake system (magnetic brake), up/down limit switches, and anti-overload protection for maximum safety.

  • High Efficiency & Easy Operation: The advanced 3-in-1 transmission system and ergonomic design make this hoist efficient and easy to operate.

  • Customizable Options: Available in various models (HSYL0.5-01, HSYL7.5-03, etc.) with customizable lifting capacities and speeds.

Product parameter:
Low Headroom Electric Chain Hoist With Traveling Trolley Safe Operation
Type Capacity
(Ton)		 Lifting Height
(m)		 Lifting speed
(m/min)		 Lifting Moter Operating Moter
Power
(kw)		 Rotation speed
(r/min)		 Phases voltage
(V)		 Frequency
(Hz)		 Power
(kw)		 Rotation speed
(r/min)		 Phases voltage
(V)		 Frequency
(Hz)
HSYL0.5-01 0.5 3/9 7.2 1.1 1440 3 220-440 50/60 0.2 1440 3 220-440 50/60
HSYL01-02 1 3/9 3.6 1.1 1440 3 220-440 50/60 0.4 1440 3 220-440 50/60
HSYL01-01 L 3/9 6.8 1.5 1440 3 220-440 50/60 0.4 1440 3 220-440 50/60
HSYL02-02 2 3/9 3.4 1.5 1440 3 220-440 50/60 0.4 1440 3 220-440 50/60
HSYL02-01 2 3/9 6.6 3.0 1440 3 220-440 50/60 0.4 1440 3 220-440 50/60
HSYL03-03 3 3/9 2.2 1.5 1440 3 220-440 50/60 0.75 1440 3 220-440 50/60
HSYL03-02 3 3/9 3.3 3.0 1440 3 220-440 50/60 0.75 1440 3 220-440 50/60
HSYL03-01 3 3/9 5.6 3.0 1440 3 220-440 50/60 0.75 1440 3 220-440 50/60
HSYL05-02 5 3/9 2.8 3.0 1440 3 220-440 50/60 0.75 1440 3 220-440 50/60
HSYL7.5-03 7.5 3/9 1.8 3.0 1440 3 220-440 50/60 0.75 1440 3 220-440 50/60
