The OWP-BL43-426T Electronic Coolant Pump is specifically engineered for electric insulating oil circulation, making it a critical component in various industrial and electronic systems. In power transformers, it ensures efficient circulation of insulating oil, which plays a vital role in dissipating heat generated during transformer operation. By maintaining a steady flow of insulating oil, the pump prevents overheating, thus safeguarding the transformer's core and windings from damage and extending its service life.

In high-voltage switchgear, the pump facilitates the circulation of insulating oil to insulate electrical components and cool them down. This is essential for ensuring the reliable operation of the switchgear, as it prevents electrical breakdowns caused by overheating and maintains the insulation performance of the oil even under high-voltage conditions. Additionally, in industrial motors and generators that use insulating oil for cooling and insulation, the pump ensures a continuous and uniform flow of oil, effectively removing heat from the motor windings and bearings, and enhancing the overall efficiency and durability of the equipment.

• Superior Motor Efficiency:

  Through professional electromagnetic theory design and verification, the pump's motor achieves an efficiency that is 3-5% higher than that of competitors' products. This higher efficiency translates to lower energy consumption, reducing operational costs while delivering reliable performance.

• Optimized Hydraulic Performance:

  The impeller and volute of the pump are designed using professional software for simulation calculation, ensuring an optimal match between the two components. This results in higher hydraulic efficiency, enabling the pump to deliver a stable and powerful flow rate even under varying operating conditions.

• Exceptional Environmental Resistance:

  Equipped with automotive-grade electronic components, the pump can withstand extreme harsh operating environments, including wide temperature fluctuations, high humidity, and vibration. This makes it suitable for use in demanding industrial settings where reliability and durability are crucial.

• Constant flow controlling
• Reverse polarity protection
• Dry running protection
• Over Voltage and over current protection
• Overload and over temperature protection
• Single-stage Centrifugal pump
• Magnetic force transmission (shield pump structure)
• High efficiency brushless DC motor with low power consumption
