500kg 1000kg Electric Drum Rotator Semi-Electric Lifter Truck Semi-Electric Stacker With Rotation Degree Of 90 180 360
500kg 1000kg Electric Drum Rotator Semi-Electric Lifter Truck Semi-Electric Stacker With Rotation Degree Of 90 180 360
500kg 1000kg Electric Drum Rotator Semi-Electric Lifter Truck Semi-Electric Stacker With Rotation Degree Of 90 180 360
500kg 1000kg Electric Drum Rotator Semi-Electric Lifter Truck Semi-Electric Stacker With Rotation Degree Of 90 180 360
500kg 1000kg Electric Drum Rotator Semi-Electric Lifter Truck Semi-Electric Stacker With Rotation Degree Of 90 180 360
500kg 1000kg Electric Drum Rotator Semi-Electric Lifter Truck Semi-Electric Stacker With Rotation Degree Of 90 180 360
Specifications
Brand Name :
KAD
Model Number :
BM050CG-16
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 units
Price :
$6000-$8500/units
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50units/month
Delivery Time :
7 working days
Packaging Details :
iron pallet+plastic film
Load capacity :
10-1000kg
Lifting height :
1000-4500mm
Load centre :
500mm
Tire :
PU Wheel
Battery power :
24V/210Ah
Description

500kg 1000kg Electric Drum Rotator Semi-Electric Lifter Truck Semi-Electric Stacker With Rotation Degree Of 90 180 360

INTRODUCTION

Electric paper roll stacker is a special equipment used for handling and transporting paper rolls. It is usually driven by an electric motor and moves through wheels or tracks. Electric paper roll stackers are commonly used in paper processing factories, printing factories, paper warehouses, and other places to transport various paper products.Electric paper roll stackers play an important role in the paper processing and transportation industry. It can effectively improve handling efficiency, reduce labor costs, and also ensure the safety of paper products during the handling process.

MAIN FEATURE

1. Strong load-bearing capacity: capable of stackerrying large paper rolls with certain load-bearing capacity.
2. High flexibility: It generally has turning
flexibility and can turn freely in narrow passages, making it easy to operate flexibly in factory workshops.
3. Good safety performance: Usually equipped
with safety protection devices, such as braking systems, safety protection devices, etc., can ensure safety during
transportation.
4. Electric drive: Generally, an electric
drive system is used, which is easy to operate and does not pollute the environment.

PRODUCT PARAMETERS

Power source
Battery
Rated load
kg
700kg/customized
Load center
mm
500
Operation way
Standing operation,electric lifting,electric gripper,electric rotating,electric moving
Turning radius
mm
1050
Aisle width
mm
1900
Length
mm
760
Width
mm
2100/customized
Mast
mm
1-stage mast
Adjustable extent of clamp
mm
200~1250
Max height of forks
mm
1500
Min height of forks
mm
200
Rotation angle
°
90°(left and right)/360 degree
Hoisting speed(load/unload)
mm/s
110/160
Descent speed(load/unload)
mm/s
150/130
Climbing capability
％
3.5
Braking mode
Wheel brake
Tyres material
Nylon
Load wheel dimensions
mm
85*80,2pcs
Steering wheel dimensions
mm
180*50,2pcs
Hydraulic motor
kw
24v/2.2kw
Battery
v/ah
24/210
Weight
kg
1100

500kg 1000kg Electric Drum Rotator Semi-Electric Lifter Truck Semi-Electric Stacker With Rotation Degree Of 90 180 360

500kg 1000kg Electric Drum Rotator Semi-Electric Lifter Truck Semi-Electric Stacker With Rotation Degree Of 90 180 360

Application of Electric Stacker
All electric clamping forklift truck, electric lift, automatic clamping, widely used in the paper industry, packaging industry, printing industry, textile industry handling, suitable for paper tubes, carpets, fabrics, cables, wood, steel coils, ropes and cables, tyres, paper rolls, fabric rolls, cables, refrigerators and rolls of film or the various industries of the round or square object warehouse workshop goods handling, shifting, automatic clamping, palletising, electric overturning and other work.
