9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
Specifications
Place of Origin :
China
Brand Name :
DUHM
Model Number :
WBC-9.0H-B-S
MOQ :
10
Price :
Negotiable
Packaging Details :
Carton
Delivery Time :
25-30 Working Days
Payment Terms :
T/T，L/C AT SIGHT
Supply Ability :
800 SETS/DAY
After-sales Service Provided :
Free spare parts
Warranty :
1 Year
Operating Language :
English
Application :
Garage, Household
Power Source :
Electric
App-Controlled :
Yes
logo/pattern :
Silk screen printing, Laser Printing
Type :
Air Source Heat Pump
Installation :
Freestanding
Storage / Tankless :
Instant / Tankless
Housing Material :
Metal, Galvanized Steel with Powder coated
Use :
Bathroom
Product Name :
R410A Hot Water Heater
Refrigerant :
R410A
Heating Source :
Air to Water Heat Pump
Function :
Domestic Hot Water
Heating Capacity(A20/15℃,W 15/55℃) :
9.25 kW
Compressor :
Vortex
Power Supply :
220~240V/1/50Hz/
Operating Ambient Temperature :
-10°C~45°C
Water Flow :
1.59 m³/h
Description
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
Model
WBC-9.0H-B
WBC-17.5H-B-S
WBC-35.0H-B-S
WBC-50.0H-B-S
Heating Condition 1-Ambient Temp. (DB/WB): 20/15℃, Water Temp. (In/Out): 15/55℃
Heating capacity
kW
9.25
17.15
34.35
47.05
COP
W/W
4.08
4.07
4.08
3.82
Hot Water Volume
L/H
199
369
738
1011
Power input
kW
2.27
4.21
8.42
12.32
Current input
A
10.85
7.54
15.06
22.03
Heating Condition 2-Ambient Temp. (DB/WB): 7/6℃, Water Temp. (In/Out): 9/55℃
Heating capacity
kW
7.71
14.29
27.48
38.57
COP
W/W
3.2
3.15
3.18
3.21
Power input
kW
2.41
4.54
8.64
12.02
Current input
A
11.53
8.12
15.46
21.49
Max power input
kW
3.40
6.32
12.63
18.48
Max current input
A
16.27
11.31
22.59
33.10
Power supply
V~Hz
220V ~ 50Hz
380V 3N~ 50Hz
380V 3N~ 50Hz
380V 3N~ 50Hz
Operating ambient temperature
°C
-10~45
Water Flow Volume
m³/h
1.59
2.95
5.91
8.09
Water Pressure Drop
kPa
40
40
60
60
Outlet Water Temp.
°C
55
Max.Outlet Water Temp.
°C
60
Water Connection
inch
G1"(DN25)
G1"(DN25)
G1.5"(DN40)
G1.5"(DN40)
Water pump
qty
0
0
0
0
Compressor
qty
1
1
1
1
Fan motor
qty
1
1
2
2
Noise
dB(A)
52
53
54
55
Net dimension
L / W / H
mm
1120*430*690
1020*380*1050
1120*430*1600
1120*430*1600
Package dimension
L / W / H
mm
1200*480*810
1100*430*1170
1200*480*1735
1200*480*1735
Net weight
kg
77
92
197
197
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
9 kw Air to Water R410A Heat Pump Water Heater Wrmepumpe with Flexible Installation
