CS Flanged PN25 Gear Operated 304 Disc Triple Offset Butterfly Valve

Product Features

WCB offers high pressure resistance and cost-effectiveness; CF8M resists chlorine and pitting corrosion; DN500 provides smooth flow in large-diameter applications; PN25 ensures stable load-bearing capacity under medium to high pressure. Designed for large-diameter pipelines carrying chlorine-containing, mildly corrosive, and non-corrosive media, these valves feature a cost-effective and reliable carbon steel base. The 316 stainless steel cast butterfly disc resists chloride ion corrosion, while the Stellite alloy sealing surface ensures long-lasting wear resistance. With a choice of drive options, they achieve reliable, leak-free shutoff.

Product Advantages

● The valve strictly adheres to the PN25 medium-to-high pressure rating, ensuring the rigidity of the forged body. It fully withstands water hammer pulses and thermal cycling, guaranteeing no structural deformation and consistently reliable sealing even under frequent opening and closing.
● For DN500 large-diameter applications, the operating torque is significantly lower than that of gate valves and ball valves of the same specification, substantially reducing the cost of selecting an actuator.
● The automatic wedging effect ensures that as medium pressure increases, the sealing contact pressure increases as well, resulting in a tighter seal with each closure, thereby exponentially extending the service life of both the valve and the actuator.

Design Standards

Product detail

Application

Chemical and Petrochemical Industries,Power Generation, Water Treatment and Environmental Protection,Metallurgy and Shipbuilding.

About Us

Zhejiang Yugong Fluid Technology Co., Ltd. is a comprehensive high-tech enterprise integrating production and sales. The company manufactures and operates professional butterfly valves made of stainless steel, carbon steel, titanium and other materials. Founded in 2012, the company is located in Yongjiao Oubei, the "hometown of pumps and valves in China", covering an area of 4,000 square meters and has more than 80 employees. Aiming high and forging ahead, the company looks forward to working hand in hand with new partners and walking all the way!

Our Workshop

F&Q

Customer Service

1. Before signing an official contract with our customer we will help to analyze and provide professional solution based on customer project information and come out with optimum solution.
2. Your inquiry related to our products or price will be replied in 24hrs.
3. Keep informing our customer production process and help arrange quality checking in the factory if necessary.
4. one-year warranty toproducts.
