hydraulic oil filter press machine price
hydraulic oil filter press machine price
hydraulic oil filter press machine price
hydraulic oil filter press machine price
hydraulic oil filter press machine price
hydraulic oil filter press machine price
hydraulic oil filter press machine price
hydraulic oil filter press machine price
Specifications
Place of Origin :
henan
Brand Name :
blackstone
Model Number :
XY
Certification :
CE&ISO
Description

XY series small filter press machine

Technical characteristics:

1, There are two kinds of hydraulic pressure device

One is called "hydraulic pressure locknut locking type". After hydraulic pressure, lock the piston rod with lock nut. It is composed by reciprocating hydraulic cylinder, lock nut and returned piston. In order to avoid the leakage from seal ring of piston and valve, the lock nut locks the piston rod to prevent the pressure plate moving.

The other is automatic pressurize type. Automatic pressurize type or automatic pulling plate type filter press, after press the plate frame, it is no need to lock the piston rod with lock nut. It depends on the electric control and check valve to control pressurize automatically. This could prevent the leakage from plate frame in the filtering process.

2, Hydraulic pressure type filter press is easy to operation. It saves time and labour. The pressure and the stress can appear on the pressure gauge. Operate the machine according to the operation technical requirements. The maintenance rate is low

3, Plate frame material: polypropylene, casting iron, rubber, stainless steel etc

Technology parameters

Formfilter press modelfilter area(m2)size (mm)cake thickness (mm)qty of platechamber volume(L)filter pressure(Mpa)sizeweight (kg)
length (mm)width (mm)height (mm)
320XS1/320-30U1320*3203041511200660650340
XS2/320-30U29311515390
XS3/320-30U314461755440
450XS4/450-30U1450*450309610.61860870870680
XS6/450-30U614912120730
XS8/450-30U8191222380790
XS12/450-30U12291822880900
XS16/450-30U163924333801000
630X20/630-30U20630*63030242980.63350115011501870
X30/630-30U303745340002190
X40/630-30U404759546002450
800X50/800-30U50800*80030387490.64205140013002790
X60/800-30U604690246703040
X70/800-30U7054105651153300
X80/800-30U8062121055603550
1000X50/1000-30U501000*100030287520.53800145013503080
X60/1000-30U603490842603330
X70/1000-30U7040106445203580
X80/1000-30U8045119448203790
X90/1000-30U9051134951704040
X100/1000-30U10057150555304290
X120/1000-30U12068179062004750
1250X100/1250-30U1001250*1250303615190.54500175015504960
X120/1250-30U12043180749105420
X140/1250-30U14050209453205890
X160/1250-30U16058242358006410
X180/1250-30U18065271062106870
X200/1250-30U20072299867207330
X250/1250-30U25090373777508480
