Specifications
Drilling Diameter :
75-325mm
Maximum lifting weight of vertical shaft :
25KN
After-sales service provided :
Online support
Final hole diameter :
75mm
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,
Brand Name :
SANROCK
Feature :
High Drilling Efficiency,portable，Light Weight
Delivery Time :
15-25days
Vertical shaft travel :
450mm
Usage :
water well.core sample
Rated speed :
2200r/min
Price :
negotiable
Type :
Core Drilling Rig
Certification :
CE ISO 9001:2015
Application :
Geological Exploration
Drilling Depth :
200m
Supply Ability :
5000Set/Sets per Month
Packaging Details :
Nude package for machines, Wooden box package for spare parts, Or customer demand.
Maximum feed pressure of vertical shaft: :
15KN
Product name :
hydraulic core drilling rig
Dimension(l*w*h) :
2700*900*1500mm
Single package size :
2150×880×1560 mm
Model Number :
SRC200
Name :
borehole drilling rig,core drilling rig
MOQ :
1Set/Sets per Month
Power :
16.2KW
Vertical shaft speed(4th gear) :
71,142,310,620 r/min
Drill rod diameter :
42-60mm
Maximum output torque of vertical shaft :
15KN
Place of Origin :
Zhejiang, China
Hole dip Angle :
90-75°
Single gross weight :
760 kg
Description

The 200-meter deep exploration core drilling rig is a highly efficient and reliable piece of equipment specifically designed for obtaining high-quality rock and soil core samples at depths of up to 200 meters.

It is widely used in geological surveys, mineral exploration, geotechnical engineering, and environmental investigations. The rig features a robust hydraulic system, variable rotation speed, and precise feeding control, ensuring smooth and consistent coring operations in various terrains. Equipped with a wireline coring system and diamond-impregnated drill bits, it delivers excellent core recovery rates with minimal disturbance to the sample structure.

Compact and portable in design, this rig is suitable for both indoor and outdoor operations, offering easy transportation and quick setup. Its advanced control panel and safety mechanisms make it user-friendly and safe for operators. With stable performance and low maintenance requirements, the 200-meter deep exploration core drilling rig is an ideal choice for efficient core sampling and subsurface investigation.

Small Core Drilling Rig High Performance Geotechnical Drilling Machine Rock Core Drilling Rig

Small Core Drilling Rig High Performance Geotechnical Drilling Machine Rock Core Drilling Rig

Small Core Drilling Rig High Performance Geotechnical Drilling Machine Rock Core Drilling Rig

Small Core Drilling Rig High Performance Geotechnical Drilling Machine Rock Core Drilling Rig

Small Core Drilling Rig High Performance Geotechnical Drilling Machine Rock Core Drilling Rig

Small Core Drilling Rig High Performance Geotechnical Drilling Machine Rock Core Drilling Rig

Small Core Drilling Rig High Performance Geotechnical Drilling Machine Rock Core Drilling Rig

Small Core Drilling Rig High Performance Geotechnical Drilling Machine Rock Core Drilling Rig

Small Core Drilling Rig High Performance Geotechnical Drilling Machine Rock Core Drilling Rig


Small Core Drilling Rig High Performance Geotechnical Drilling Machine Rock Core Drilling Rig

Small Core Drilling Rig High Performance Geotechnical Drilling Machine Rock Core Drilling Rig


Products Description

Brand Name:SANROCK
Product name :Core Drilling Rig

Name: Core Drilling Machine
Power Type :Diesel

Feature :High Drilling Efficiency,portable,Light Weight
Packaging Details:packing according to customer's requirement.

Model number:Diesel engine
Rated speed:2200r/min
Power:16.2KW
Borehole depth:200M
Pipe diameter:50mm
Opening diameter:75-325mm
Final hole diameter:75mm
Hole dip Angle:90-75°
Gyrator
Vertical shaft speed(4th gear):71,142,310,620 r/min
Vertical shaft travel:450mm
Maximum output torque of vertical shaft:15KN
Maximum feed pressure of vertical shaft:15KN
Maximum lifting weight of vertical shaft:25KN
Single package size:2150×880×1560 mm
Single gross weight:760 kg
