Specifications
Brand Name :
SANROCK
Model Number :
SR-500RC
Certification :
CE ISO 9001:2015
Place of Origin :
Zhejiang, China
MOQ :
1Set/Sets per Month
Price :
negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
5000Set/Sets per Month
Delivery Time :
15-26 work days
Packaging Details :
Nude package for machines, Wooden box package for spare parts, Or customer demand.
Product name :
core drilling rig ,core drilling machine
Name :
borehole drilling rig,water well drilling machine,core drilling rig
Type :
Core Drilling Rig
Keyword :
Reverse Circulation Drilling Rig
Power type :
Diesel
Power(w) :
132KW
Drilling depth :
500m
Drilling diameter :
140-400mm
Lifting force :
12KN
Rotary torque :
8000-12000 N.m
Rotate speed :
40-160rpm
Working pressure :
1.7-3.5Mpa
Drill pipe diameter :
76/89/102/114mm
Drill pipe length :
1.5/2.0/3.0m
Application :
coring machine,coal，Geological Exploration
Usage :
Coal,water well.core sample
Feature :
High Drilling Efficiency,Hydraulic Controlling,Multifunctional
After-sales service provided :
Online support
Weight :
12000KG
Description

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

The Golden Soil Investigation Reverse Circulation (RC) Core Drill is a specialized drilling rig designed for efficient and accurate sampling of gold-bearing soil and geological formations. It employs a reverse circulation system that ensures minimal contamination and high sample recovery by using dual-wall drill rods. Compressed air circulates cuttings to the surface through the annular space, providing continuous, representative core samples for analysis. Ideal for mineral exploration, this drill offers rapid penetration, depth capability, and reliable performance in varied terrains, making it essential for assessing gold deposit potential.

The Dual-Wall Drill Rod Reverse Circulation (RC) Core Drill is a highly efficient drilling system engineered for superior sample integrity in geological exploration and mineral prospecting. Its core technology utilizes dual-wall drill rods, consisting of an inner and an outer tube. During operation, compressed air or fluid is pumped down the annulus between the two tubes, driving the drill bit. The resulting cuttings are then forced up through the inner tube in a continuous, sealed flow.

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling MachineGold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine
Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

This is just a part of the overseas clients who came to our company to negotiate cooperation, sign contracts and take photos.
We welcome more overseas clients to come to our company for negotiation and cooperation.

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Product Description


Drilling capacity
Drilling depth(m)
500
The hole diameter(mm)
140-400
Drill pipe diameter(mm)
76/89/102/114
Drill pipe length(m)
1.5/2/3
Axial pressure(kN)
100
Drive head
Rotation torque(N.m)
8000-12000
Rotation speed(rpm)
40-160
Stroke(m)
1.7-3.5
Rig lifting force(kN)
300
Feeding capacity(kN)
150
Rapid rise speed(m/min)
20
Fast feeding speed(m/min)
40
Power Unit
Rated power/speed(kW/rpm)
132/2400
Tool winch capacity
Lifting force(kN)
20
Air compressor
Air pressure(MPA)
1.7-3.5
Air consumption(m³/min)
17-42
Equipped with hammer(Reverse circulation)
Medium and high pressure series
Crawler chassis
Walking speed(km/h)
2.5
Climbing angle(°)
30
Dimension
Transport(mm)
6450*2100*2700
Working(mm)
4500*4000*7000
Weight
Weight(t)
12


Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling MachineGold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling MachineGold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Company Profile

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

Gold Core Drilling Rig Reverse Circulation RC Drilling Rig Soil Investigation Drilling Machine

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.


2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.


3.How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.


4.How is your quality control? A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
