Electric Heating Stainless Steel Drying Oven Industrial Hot Air Oven 2300*1200*2000
Electric Heating Stainless Steel Drying Oven Industrial Hot Air Oven 2300*1200*2000
Electric Heating Stainless Steel Drying Oven Industrial Hot Air Oven 2300*1200*2000
Electric Heating Stainless Steel Drying Oven Industrial Hot Air Oven 2300*1200*2000
Electric Heating Stainless Steel Drying Oven Industrial Hot Air Oven 2300*1200*2000
Electric Heating Stainless Steel Drying Oven Industrial Hot Air Oven 2300*1200*2000
Specifications
MOQ :
1 Set
Delivery Time :
30 days
Trays :
48
Price :
$10,000-$50,000
Overall dimension :
2300*1200*2000
Packaging Details :
Wooden crate/Wooden pallet
Model Number :
CT-C-III
Material :
SUS304/316L
Payment Terms :
T/T
Supply Ability :
100 Set/year
Certification :
ISO9001
Heat source :
Electric
Place of Origin :
CHINA
Batch drying capacity :
50-300kg
Brand Name :
YIXIN
Name :
Stainless Steel Drying Oven
Description

Stainless Steel Electric Heating Hot Air Oven For Heat Sensitive Materials

I, Basic structure

The equipment consists of a chamber, heater (electric heating tubes or steam radiator), high-flow circulation fan, and moisture exhaust system. During operation, the fan delivers clean, heated air from the heater into the chamber interior. The hot air flows uniformly through the material layer placed on trays via air ducts, making full contact with the material to remove moisture. A portion of the moist exhaust gas is discharged, while another portion is mixed with fresh air and reheated for recirculation, creating a forced hot air circulation that ensures uniform temperature throughout the chamber (typically with a temperature variation of ≤±2℃). Currently, the mainstream model is the CT-C type, which uses louvered dampers to adjust airflow direction, further enhancing temperature uniformity.

II, Main advantages:
Wide applicability: Suitable for drying irregularly shaped materials and small-batch products without the need for frequent equipment changes.
Precise temperature control: Equipped with an intelligent temperature controller that allows segmented setting of heating curves to meet different drying process requirements for various materials.
Easy operation: After loading materials onto trays, simply push them into the chamber for sealed baking—simple process and easy maintenance.
