100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module
100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module
100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module
100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module
100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module
100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module
100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module
100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module
100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module
100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module
Specifications
Model Number :
UND-JM100
Place of Origin :
China
Brand Name :
UND
MOQ :
1
Price :
Please consult a sales engineer
Delivery Time :
5-8 days
Payment Terms :
T/T
Supply Ability :
100
Type :
RF Module
Output Power :
100W
Frequency Range :
1100-1500 MHz
Working Voltage :
28V
Working current :
8 - 10A
Installation Dimension :
144.3*74*22 mm
Weight :
800g
Description
100W 300-600MHz Broadband FPV Electronic Amplifier Module Wireless & RF Wireless & RF Modules100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module
Item
Spec.
Remarks
Frequency Range
1100-1500 MHz
Bandwidth Range±10MHz
Working Voltage
28V;
28V
Working current
8 - 10A
output 100W
Analog sweeping speed
220 KHz
8μ/s
Output Power (Max)
50±1 dBm
100W
Gain (Max)
50±1 dB
Ripple in Band
≤ 4 dB
Peak
Bandwidth adjustment
Yes
By screw
Center adjustment
Yes
By screw
Enable control
Customize
24-28V
Input power (Max)
≤ +10dBm
Optional (If signal source from Subscriber)
Input Signal Source
Built-in high-speed noise modulation signal source
Optional
(can customize VCO, DDS or SDR)
Output VSWR
≤2.0
Inside circulator, VSWR protect
High Low
Temperature test
Working Temperature
-20~+65℃
Working properly
Gain Stability
±1 dB
at
-20℃~+65℃
Power stability
±1 dB
at
-20℃~+65℃
Power supply Port
Positive and negative lines
28V; GND;
(optional: Enable control wire)
Shell Material
Aluminum with natural color oxide sand blasting
Vibration Need
Meet the load need of moving vehicle
RF output connector
N-Female
LED indicator light
Power ON/OFF
Dimension
150*80*22mm
Installation Dimension
144.3*74*22 mm
Screw Size
M2.0
Weight
800g

100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module
ABOUT US
100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module

Certification

100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module100W Anti Drone Module 300MHz - 600MHz Signal Jammer Module

1. How long is the production lead time?
The production lead time varies depending on the product and order quantity. Generally, it takes around 7-15 days after receiving the deposit. Please contact us for more accurate information based on your order.
2. Can I customize the product?
Yes,Power and frequency band can be customized according to your needs
Please contact us with your specific requirements.
3. What is your payment term?
We accept various payment methods, including T/T (Telegraphic Transfer), PayPal, and Alibaba Trade Assurance.
Payment terms are typically 30% deposit and 70% balance before shipment.
4. How do you ensure product quality?
We have a strict quality control process, including raw material inspection, in-production checks, and final quality inspections before shipment.
5. What shipping methods are available?
We offer multiple shipping options, including sea freight, air freight, and express courier (DHL, FedEx, UPS, etc.). We will
recommend the most suitable method based on your order quantity and destination.
6. Can I track my order?
Yes, we will provide you with a tracking number once your order is shipped.
You can use this number to track your order through the carrier's website.
7. Do you provide after-sales service?
Yes, we offer comprehensive after-sales support, including technical assistance and warranty services.
Please contact our customerservice team for any issues related to your order.
